The A10MKII Integrated Amplifier offers the perfect combination of power and style for the music lover seeking to elevate their listening experience. Constructed with a massive Rotel-built toroidal transformer, the A10MKII delivers 50 Watts per channel of Class A/B power into 8 ohms featuring three RCA inputs and a Moving Magnet Phono stage for vinyl lovers . The A10MKII Integrated Amplifier offers the perfect combination of power and style for the music lover seeking to elevate their listening experience. Constructed around a linear power supply featuring a massive Rotel-built toroidal power transformer, the A10MKII delivers an authoritative 50 Watts per channel of Class A/B power into 8 ohms, and even higher into more challenging loudspeakers. All analog sources are welcome, with three line-level RCA inputs, and a Moving Magnet compatible Phono stage provided for vinyl lovers. An 1/8” headphone jack with dedicated headphone amplifier circuit is provided on the front panel for private listening sessions. An intuitive front panel layout includes rotary Bass, Treble, and Balance controls making the A10MKII a joy to use up close, while the included IR remote control, and a motorized analog volume controller extend ease of use to the listening seat. The A10MKII is available in both black and silver colors. Features 50 watts x 2 channels into 8 ohms (20-20,000 Hz) at 0.03% THD Class AB amplification with custom-designed toroidal transformer frequency response: 10-100,000 Hz (line inputs, -0.5dB/+0.05dB); 20-20,000 Hz (phono input, -0.5/+0.3dB) signal-to-noise ratio: 90 dB (line); 85 dB (phono) front-panel volume, balance, and tone controls detachable power cord remote control Specifications POWER OUTPUT 50W/Ch (8Ω) TOTAL HARMONIC DISTORTION (THD) <0.03% FREQUENCY RESPONSE Line Level Inputs: 10Hz - 100kHz, -0.5dB, +0.05dB Phono Input: 20Hz - 20kHz, -0.5dB, +0.3dB S/N RATIO (IHF "A" Weighted) Line Level Inputs: 90dB Phono Input: 85dB DIMENSIONS (W × H × D) 430 × 73 × 347mm 17" × 2-7/8" × 13-5/8" FRONT PANEL HEIGHT 60 mm (2 3/8”) POWER REQUIREMENTS 230V, 50Hz POWER CONSUMPTION 150W STANDBY POWER CONSUMPTION <0.5W NET WEIGHT 6.6kg (14.5lbs.) BTU RATING (4Ω, 1/8th power) 450 BTU/h INTERMODULATION DISTORTION (60Hz:7kHz, 4:1) <0.03% DAMPING FACTOR 120 INPUT SENSITIVITY Line Level Inputs: 120mV Phono Input (MM): 1.5mV INPUT IMPEDANCE Line Level Inputs: 45kΩ Phono Input (MM): 43kΩ INPUT OVERLOAD Line Level Inputs: 4V Phono Input: 50mV TONE CONTROLS ±6dB at 100Hz / 10kHz Support Datasheet Manual About Rotel For over six decades Rotel has been engineering, manufacturing, and delivering audio products built to the highest standards of quality, with extraordinary performance and exceptional value. This Japanese family owned, and family operated business leverages the tradition and heritage of this 60-Year old icon brand supported by innovation and passion delivering products proud to wear the Rotel badge building our ever-growing extended Rotel family of customers including audiophiles, music lovers, musicians, recording artists and loyal fans.

The A11MKII Integrated Amplifier delivers the ideal combination of power and connectivity for anyone seeking to elevate their listening experience. Constructed around a massive Rotel-built toroidal power transformer, the A11MKII delivers 50 Watts per channel of Class A/B power into 8 ohms supporting analog, digital and Moving Magnet Phono stage inputs. The A11MKII Integrated Amplifier offers an ideal combination of power and connectivity for the music lover seeking to elevate their listening experience. Constructed around a linear power supply featuring a massive Rotel-built toroidal power transformer, the A11MKII delivers an authoritative 50 Watts per channel of Class A/B power into 8 ohms, and even higher power into demanding loudspeakers. Both analog and digital sources are welcome, with three line-level RCA inputs, coaxial and optical digital inputs, a Moving Magnet Phono stage, and aptX™ HD Bluetooth. An 1/8” headphone jack with dedicated headphone amplifier circuit is provided on the front panel for private listening sessions. The intuitive front panel layout includes Bass, Treble, and Balance rotary controls and source input selection ensuring the A11MKII is personal and a pleasure to operate up close. The included IR remote drives a motorized analog volume controller for ease of use at the listening position. The A11MKII is available in both black and silver colors. Features 50 watts x 2 channels into 8 ohms at 0.03% THD Class AB amplification with custom-designed toroidal transformer wireless Bluetooth with high-quality aptX HD and AAC coding frequency response: 10-100,000 Hz (line inputs, -0.5dB/+0.05dB); 20-20,000 Hz (phono input, -0.5dB/+0.3dB) signal-to-noise ratio: 90 dB (line); 85 dB (phono) front-panel volume, balance, and tone controls detachable power cord remote control Specifications POWER OUTPUT 50W/Ch (8Ω) 62W/Ch (4Ω) TOTAL HARMONIC DISTORTION (THD) <0.03% FREQUENCY RESPONSE Line Level Inputs: 10Hz - 100kHz, -0.5dB, +0.05dB Phono Input: 20Hz - 20kHz, -0.5dB, +0.3dB S/N RATIO (IHF "A" Weighted) Line Level Inputs: 90dB Phono Input: 85dB DIMENSIONS (W × H × D) 430 × 73 × 347mm 17" × 2-7/8" × 13-5/8" FRONT PANEL HEIGHT 60 mm (2 3/8”) POWER REQUIREMENTS 230V, 50Hz POWER CONSUMPTION 150W STANDBY POWER CONSUMPTION <0.5W NET WEIGHT 6.8kg (15lbs.) BTU RATING (4Ω, 1/8th power) 450 BTU/h INTERMODULATION DISTORTION (60Hz:7kHz, 4:1) <0.03% DAMPING FACTOR 120 INPUT SENSITIVITY Line Level Inputs: 130mV Phono Input (MM): 1.6mV INPUT IMPEDANCE Line Level Inputs: 45kΩ Phono Input (MM): 43kΩ INPUT OVERLOAD Line Level Inputs: 4V Phono Input: 50mV TONE CONTROLS ±6dB at 100Hz / 10kHz Support Datasheet Manual About Rotel For over six decades Rotel has been engineering, manufacturing, and delivering audio products built to the highest standards of quality, with extraordinary performance and exceptional value. This Japanese family owned, and family operated business leverages the tradition and heritage of this 60-Year old icon brand supported by innovation and passion delivering products proud to wear the Rotel badge building our ever-growing extended Rotel family of customers including audiophiles, music lovers, musicians, recording artists and loyal fans.

The Rotel A12MKII stands well above its sleek design delivering 60 Watts of dynamic Class AB output into 8 ohms. This integrated amplifier supports your favorite sources including MM Phono Stage, analog, digital, PC-USB and wireless Bluetooth. Optimized circuits and a 32-bit DAC deliver spacious and open reproduction of the music. The A12MKII Integrated Amplifier measures only a slim 80 mm (3 inches) tall but stands well above its sleek design profile in performance and feature set for all music lovers. The heart of the A12MKII begins with Rotel’s in-house manufactured oversized toroidal transformer feeding high efficiency storage and smoothing capacitors for deep, controlled bass energy. The power supply features multiple voltage and current regulators delivering independent power to critical analog, digital and amplification stage circuits isolating sensitive low voltage signals from high power speaker outputs lowering the noise floor and reducing unwanted distortion. Circuit design follows Rotel’s proprietary Balanced Design Concept with physical and electrical isolation techniques delivering exceptionally clean audio. The A12MKII is replete with inputs supporting your favorite sources including a Moving Magnet Phono Stage for vinyl fans, 4 RCA analog, 4 digital, PC-USB and high quality aptXTM Bluetooth for wireless streaming. A premium 32-bit Texas Instruments Digital to Analog converter extracts genuine and accurate details of the music with custom output filters and preamplifier circuits preserving the integrity of the audio stream. The Class AB amplifier delivers 60 Watts of dynamic power into 8 ohms utilizing high current, fast transient output devices for improved accuracy of the music timing and a more lifelike reproduction of audio into dual A-B speaker binding posts. The IR remote, front panel controls, and graphic display ensure effortless operation. RS232, 12V triggers and remote input ensure seamless integration with control systems. Slim and powerful the A12MKII delivers on Rotel’s iconic brand heritage. Features 2 x 60 Watts of robust Class AB power Texas Instruments premium 32-bit/384kHz Digital to Analog Converter Wireless aptXTM Bluetooth Moving Magnet Phono Input for Turntable connection Specifications MAXIMUM POWER OUTPUT 120W/Ch (4Ω) CONTINUOUS POWER OUTPUT 60W/Ch (8Ω) TOTAL HARMONIC DISTORTION (THD) <0.018% FREQUENCY RESPONSE Line Level Inputs: 10Hz - 100kHz, 0±0.5dB Digital Inputs: 10Hz - 90kHz, 0±2dB Phono Input: 20Hz - 20kHz, 0±0.5dB S/N RATIO (IHF "A" Weighted) Line Level Inputs: 100dB Digital Inputs: 103dB Phono Input: 90dB DIMENSIONS (W × H × D) 430 × 93 × 345mm 17" × 3.6" × 13.5" FRONT PANEL HEIGHT 80mm (3.15") POWER REQUIREMENTS 230V, 50Hz POWER CONSUMPTION 230W STANDBY POWER CONSUMPTION <0.5W NET WEIGHT 8.76kg (19.31lbs.) BTU RATING (4Ω, 1/8th power) 632 BTU/h INTERMODULATION DISTORTION (60Hz:7kHz, 4:1) <0.03% DAMPING FACTOR 220 INPUT SENSITIVITY Line Level Inputs: 230mV Digital Inputs: 0dBfs Phono Input (MM): 3.4mV INPUT IMPEDANCE Line Level Inputs: 24kΩ Digital Inputs: 75Ω Phono Input (MM): 47kΩ INPUT OVERLOAD Line Level Inputs: 4V Phono Input: 50mV PREOUT LEVEL 1.2V OUTPUT IMPEDANCE 470Ω TONE CONTROLS ±10dB at 100Hz / 10kHz DIGITAL INPUT SPDIF LPCM (Up to 24-bit/192kHz) PC-USB USB Audio Class 1 (up to 24-bit/96kHz) USB Audio Class 2 (up to 32-bit/384kHz)* *Driver installation required Roon Tested Support Datasheet Manual About For over six decades Rotel has been engineering, manufacturing, and delivering audio products built to the highest standards of quality, with extraordinary performance and exceptional value. This Japanese family owned, and family operated business leverages the tradition and heritage of this 60-Year old icon brand supported by innovation and passion delivering products proud to wear the Rotel badge building our ever-growing extended Rotel family of customers including audiophiles, music lovers, musicians, recording artists and loyal fans.

The A14MKII is the flagship model in the 14 Series family of Rotel products delivering 80 Watts of Class AB amplification into 8 ohm speakers powered by Rotel’s in-house manufactured, oversized toroidal transformer and an array of 4 high efficiency slit-foil bulk storage capacitors delivering an effortless acoustic performance. A fully redesigned Digital to Analog circuit topology utilizes a Texas Instruments 32-bit/384kHz DAC with exhaustive tuning and hand selection of all critical components delivering a fuller, richer and more balanced presentation of the music. Improvements to the power supply and amplifier gain stages further refine the audio whether you are listening to a big band orchestra or a solo vocalist. Tone controls provide treble and bass adjustments in 1dB steps up to +/- 10dB personalizing your experience for all music genres, moods and settings with a BYPASS mode eliminating unwanted noise and distortion. The A14MKII supports your favorite sources including analog, digital, PC-USB with MQA, high-quality wireless aptXTM and AAC Bluetooth streaming and even a Moving Magnet Phono stage for vinyl fans. The A14MKII is certified Roon Tested delivering the best experience using Roon software so you can just enjoy the music. Control system integration is available utilizing Ethernet, RS232, 12V-Trigger and remote IR connections. Dual 5-way speaker binding posts allow Zone 2 installations with relay-controlled selection of the A-B speaker outputs. The front panel graphic display includes a large volume indication and audio stream information. The A14MKII is comfortable in any setting delivering countless hours of audio entertainment. Features 2 x 150 Watts of robust Class AB power, 4 Ohms Certified Roon Tested Supports MQA and MQA Studio Texas Instruments premium 32-bit/384kHz Digital to Analog Converter Wireless aptXTM and AAC Bluetooth Moving Magnet Phono input for turntable connection Specifications MAXIMUM POWER OUTPUT 150W/Ch (4Ω) CONTINUOUS POWER OUTPUT 80W/Ch (8Ω) TOTAL HARMONIC DISTORTION (THD) <0.018% FREQUENCY RESPONSE Line Level Inputs: 10Hz - 100kHz, ±0.5dB Digital Inputs: 10Hz - 90kHz, ±2.0dB, Max Phono Input: 20Hz - 15kHz, ±0.5dB S/N RATIO (IHF "A" Weighted) Line Level Inputs: 100dB Digital Inputs: 103dB Phono Input: 90dB DIMENSIONS (W × H × D) 430 × 93 × 345mm 17" × 3.6" × 13.5" FRONT PANEL HEIGHT 80mm (3.15") POWER REQUIREMENTS 230V, 50Hz POWER CONSUMPTION 280W STANDBY POWER CONSUMPTION <0.5W NET WEIGHT 8.94kg (19.71lbs.) BTU RATING (4Ω, 1/8th power) 632 BTU/h INTERMODULATION DISTORTION (60Hz:7kHz, 4:1) <0.03% DAMPING FACTOR 220 INPUT SENSITIVITY Line Level Inputs: 230mV Digital Inputs: 0dBfs Phono Input (MM): 3.4mV INPUT IMPEDANCE Line Level Inputs: 24kΩ Digital Inputs: 75Ω Phono Input (MM): 47kΩ INPUT OVERLOAD Line Level Inputs: 4V Phono Input: 50mV PREOUT LEVEL 1.2V OUTPUT IMPEDANCE 470Ω TONE CONTROLS ±10dB at 100Hz / 10kHz COAX/OPTICAL DIGITAL INPUT SIGNALS SPDIF LPCM (Up to 24-bit/192kHz) PC-USB USB Audio Class 1 (up to 24-bit/96kHz) USB Audio Class 2 (up to 32-bit/384kHz) *Driver installation required MQA and MQA Studio (up to 24-bit/384kHz ) Roon Tested Support Datasheet Manual Reviews & Awards Ecoustics - Apr. 2021 About Rotel For over six decades Rotel has been engineering, manufacturing, and delivering audio products built to the highest standards of quality, with extraordinary performance and exceptional value. This Japanese family owned, and family operated business leverages the tradition and heritage of this 60-Year old icon brand supported by innovation and passion delivering products proud to wear the Rotel badge building our ever-growing extended Rotel family of customers including audiophiles, music lovers, musicians, recording artists and loyal fans.

The Rotel A8 Integrated Amplifier blends power, size, efficiency, and value for music lovers yearning to enhance their musical journey. Engineered with a robust Rotel-crafted toroidal transformer driving 40 Watts per channel of Class A/B potency into 4 ohms featuring three RCA analog inputs and a Moving Magnet Phono stage tailored for vinyl enthusiasts. The A8 Integrated Amplifier is the perfect fusion of power, size, efficiency, and value tailored for music enthusiasts. Built around an in-house manufactured, high current, Rotel-crafted toroidal power transformer, the A8 delivers a commanding 40 Watts per channel of Class A/B power into 4 ohms. The high efficiency output drive transistors ensure deep bass energy is controlled with ultimate precision while comfortably maintaining composure at all listening levels. The A8 features three line-level RCA inputs connecting your favorite analogue sources complemented by a Moving Magnet compatible Phono Stage to spin classic vinyl albums. For private listening, a front panel 1/8” headphone jack is also included. The included IR remote ensures precise and seamless operation of the volume level and selection of the desired source input all from your favorite listening position. The remote also conveniently includes CD transport control functions supporting Rotel CD players. Personal selection of LED volume indicator color allows the A8 to be tailored to both mood and environment. Choose from Red, Green, Blue, or Purple LED colors fitting comfortably into any environment. Get hands-on with the front panel Bass, Treble and Balance controls to personalize the listening experience with your music. Rear panel 5-way speaker binding posts provide the ultimate installation flexibility and connection to your loudspeakers. Available in both stylish black and sophisticated silver variants, the A8 integrates the power, versatility, and elegance of your audio experience. Features 2 x 40 Watts of robust power, 4Ohms Class AB amplifier design High current power supply Includes Remote Control Moving Magnet Phono input for turntable connection Specifications POWER OUTPUT 30 W/ Ch (8 Ω) 40 W/ Ch (4 Ω) TOTAL HARMONIC DISTORTION (THD) <0.03% FREQUENCY RESPONSE Line Level Inputs: 10 Hz - 100k Hz, -0.5 dB, +0 dB Phono Input: 20 Hz - 20k Hz, -0.5 dB, +0 dB S/N RATIO (IHF "A" Weighted) Line Level Inputs: 90 dB Phono Input: 80 dB DIMENSIONS (W × H × D) 430 × 73 × 347 mm 17” x 2 7/8” x 13 5/8” FRONT PANEL HEIGHT 60 mm (2 3/8”) POWER REQUIREMENTS 120 V, 60 Hz POWER CONSUMPTION 110 W STANDBY POWER CONSUMPTION <0.5 W NET WEIGHT 5.8 kg, 12.8 lbs BTU RATING (4 Ω, 1/8th power) 340 BTU/ h Support Datasheet Manual About For over six decades Rotel has been engineering, manufacturing, and delivering audio products built to the highest standards of quality, with extraordinary performance and exceptional value. This Japanese family owned, and family operated business leverages the tradition and heritage of this 60-Year old icon brand supported by innovation and passion delivering products proud to wear the Rotel badge building our ever-growing extended Rotel family of customers including audiophiles, music lovers, musicians, recording artists and loyal fans.

Performance meets efficiency in Rotel’s C8 Class AB Custom Installation Amplifier, driving 8- channels of premium audio at 70 Watts per channel, or bridged at 140 Watts into 4-ohm loads. The C8 includes 4 Analog inputs matrixed to all Zones. Front panel display and controls provide source and independent volume, bass and treble settings. The custom 2U height requires no top or bottom clearance when rack mounting . Performance meets efficiency in Rotel’s C8 Class AB Custom Installation Amplifier, driving 8- channels of premium audio at 70 Watts per channel, or bridged at 140 Watts into 4-ohm loads utilizing Rotel’s proprietary amplification technology. The oversized in-house manufactured toroidal transformer drives sixteen output devices for effortless, controlled bass energy. For ultimate installation flexibility the C8 includes 4 Analog inputs matrixed to all Zones. Front panel display and controls provide source and independent volume, bass and treble settings. Control system integration is available via IP and RS232 interfaces and 12-Volt trigger. The custom 2U height requires no top or bottom clearance when rack mounting. The C8 is available in black only. Features 8 x 70 Watts of robust class AB power, 4 Ohms Class AB amplifier design Custom engineered toroidal transformer 12 volt trigger input Rack ears included Specifications MAXIMUM POWER OUTPUT 70W/Ch (8 channels driven, 4Ω) CONTINUOUS POWER OUTPUT 50W/Ch (8 channels driven, 8Ω) TOTAL HARMONIC DISTORTION (THD) 50dB INPUT SENSITIVITY Line Level Inputs: 0.3V INPUT IMPEDANCE Line Level Inputs: 31kΩ INPUT OVERLOAD Line Level Inputs (RCA): 2.8V Support Datasheet Manual About Rotel For over six decades Rotel has been engineering, manufacturing, and delivering audio products built to the highest standards of quality, with extraordinary performance and exceptional value. This Japanese family owned, and family operated business leverages the tradition and heritage of this 60-Year old icon brand supported by innovation and passion delivering products proud to wear the Rotel badge building our ever-growing extended Rotel family of customers including audiophiles, music lovers, musicians, recording artists and loyal fans.

Performance meets efficiency in Rotel’s C8+ Class AB Custom Installation Amplifier, driving 8-channels of premium audio at 150 Watts per channel, or bridged at 300 Watts into 4-ohm loads. The C8+ includes 4 Analog and 4 Digital inputs matrixed to all Zones. Front panel display and controls provide source selection and independent volume, bass and treble settings. The custom 2U height requires no top or bottom clearance when rack mounting . Performance meets efficiency in Rotel’s C8 Class AB Custom Installation Amplifier, driving 8- channels of premium audio at 70 Watts per channel, or bridged at 140 Watts into 4-ohm loads utilizing Rotel’s proprietary amplification technology. The oversized in-house manufactured toroidal transformer drives sixteen output devices for effortless, controlled bass energy. For ultimate installation flexibility the C8 includes 4 Analog inputs matrixed to all Zones. Front panel display and controls provide source and independent volume, bass and treble settings. Control system integration is available via IP and RS232 interfaces and 12-Volt trigger. The custom 2U height requires no top or bottom clearance when rack mounting. The C8 is available in black only. Features 8 x 150 Watts of robust class AB power, 4 Ohms Class AB amplifier design 4 individual 24-bit/192kHz Digital to Analogue Converters Custom engineered toroidal transformer 12 volt trigger input Rack ears included Specifications MAXIMUM POWER OUTPUT 150W/Ch (8 channels driven, 4Ω) CONTINUOUS POWER OUTPUT 100W/Ch (8 channels driven, 8Ω) TOTAL HARMONIC DISTORTION (THD) 50dB INPUT SENSITIVITY Line Level Inputs: 0.3V, Digital Inputs: -13.5dBfs INPUT IMPEDANCE Line Level Inputs: 31kΩ, Digital Inputs: 75Ω INPUT OVERLOAD Line Level Inputs (RCA): 2.8V DIGITAL TO ANALOG CONVERTERS Texas Instruments OPTICAL DIGITAL SIGNALS SPDIF LPCM (up to 192kHz/24-bit) Support Datasheet Manual About Rotel For over six decades Rotel has been engineering, manufacturing, and delivering audio products built to the highest standards of quality, with extraordinary performance and exceptional value. This Japanese family owned, and family operated business leverages the tradition and heritage of this 60-Year old icon brand supported by innovation and passion delivering products proud to wear the Rotel badge building our ever-growing extended Rotel family of customers including audiophiles, music lovers, musicians, recording artists and loyal fans.

The CD11MKII CD Player furthers Rotel’s 30+ year legacy of delivering high performance, high value CD players. The player’s heavy steel chassis supports a proprietary Rotel disc transport exclusively for the playback of compact discs. The CD 11MKII’s smooth, tray-loading mechanism, precise laser pickup and silent running motor controller ensures seamless, worry-free playback of your CD collection. The CD11MKII CD Player furthers Rotel’s 30+ year legacy of delivering high performance, high value CD players. The player’s heavy steel chassis supports a proprietary Rotel disc transport exclusively for the playback of compact discs. The CD11MKII’s smooth, tray-loading mechanism, precise laser pickup and silent running motor controller ensures seamless, worry-free playback of your CD collection. Digital to Analog conversion is handled by a premium Texas Instruments PCM5102A 32-bit/384kHz DAC feeding custom-tuned digital low pass filter circuits. This sound-first design renders music on a large, open sound stage with both power and finesse. Intuitive CD control functions on the front panel and included remote control ensure simple operation. The front panel graphic display shows playback status and disc meta data information including the title and artist. The CD11MKII is available in both black and silver colors. Features plays CDs and CD-Rs Texas Instruments 32-bit/384kHz digital-to-analog converter total harmonic distortion: 0.009% @ 1kHz frequency response: 20-20,000 Hz (±0.5dB) signal-to-noise ratio: >125dB Specifications TOTAL HARMONIC DISTORTION (THD) 0.009% @ 1kHz FREQUENCY RESPONSE 20Hz - 20kHz ±0.5dB S/N RATIO (IHF "A" Weighted) >125dB DYNAMIC RANGE >99dB DIGITAL TO ANALOG CONVERTERS Texas Instruments CHANNEL BALANCE ±0.5dB CHANNEL SEPARATION >115dB @ 10kHz DIMENSIONS (W × H × D) 430 × 98 × 314mm 17" × 3.8" × 12.4" FRONT PANEL HEIGHT 80mm (3.15") POWER REQUIREMENTS 230V, 50Hz POWER CONSUMPTION 15W STANDBY POWER CONSUMPTION <0.5W NET WEIGHT 6.2kg (13.7lbs.) BTU RATING 40 BTU/h INTERMODULATION DISTORTION 0.009% @ 1k Hz PHASE LINEARITY ± 0.5 degree ANALOG OUTPUT IMPEDANCE 470Ω DIGITAL OUTPUT 0.5 V, Peak to Peak LOAD IMPEDANCE 75Ω Support Datasheet Manual

The CD14MKII delivers accurate reproduction of CDs with stunning clarity resolving even the finest details. The Texas Instruments 32-bit DAC is supported by independent power supplies isolating motor controls from sensitive audio circuits reducing noise and distortion. Bring your CD collection including MP3s and let the CD14MKII deliver performance at its best. The CD14MKII follows Rotel’s proud tradition of delivering award winning CD players for over 30 years including the RCD855 launched to critical acclaim in 1989 and continuing today supporting the over 200 billion CDs sold in the market. The MKII model includes acoustic and performance upgrades and innovations including enhancements to the power supply, printed circuit board and layout design isolation techniques and new acoustically tuned audio components resulting in a more accurate reproduction of the audio with richer and genuine detail. Critical Digital to Analog conversion in the CD14MKII is managed by a premium Texas Instruments 32-bit DAC with custom tuned external analog output filters. The DAC digital and analog circuits are fed by independent voltage and current power supplies eliminating unwanted distortion and isolating motor controls from sensitive audio circuits further reducing noise and distortion. Output connections support RCA analog and coaxial digital allowing the CD14MKII to be utilized as a transport to an outboard DAC further optimizing flexibility. The smooth action tray loading CD mechanism ensures easy loading of your favorite discs with an intuitive IR remote control, front panel control buttons and a graphic display packaged in an efficiently sized 80mm (3 inches) chassis for seamless operation and the ultimate in convenience. The RS232, 12V trigger and IR remote input provide the ultimate installation flexibility including integration with popular control systems. Bring your CD collection and allow the CD14MKII to showcase your music collection both old and new with stunning detail, clarity and exceptional accuracy. Features Texas Instruments premium 32-bit/384kHz Digital to Analogue Converter Smooth tray loading CD mechanism Coax output for use as a transport Includes remote control 12v trigger input Specifications TOTAL HARMONIC DISTORTION (THD) 0.0035% @ 1kHz FREQUENCY RESPONSE 20Hz - 20kHz ±0.5dB S/N RATIO (IHF "A" Weighted) >118dB DYNAMIC RANGE >99dB DIGITAL TO ANALOG CONVERTERS Texas Instruments CHANNEL BALANCE ±0.5dB CHANNEL SEPARATION >118dB @ 10kHz DIMENSIONS (W × H × D) 430 × 98 × 314mm 17" × 3.8" × 12.3" FRONT PANEL HEIGHT 80mm (3.15") POWER REQUIREMENTS 230V, 50Hz POWER CONSUMPTION 15W STANDBY POWER CONSUMPTION <0.5W NET WEIGHT 6.51kg (14.35lbs.) BTU RATING 51 BTU/h INTERMODULATION DISTORTION 0.0035% @ 1kHz PHASE LINEARITY ±0.5 degree OUTPUT LEVEL Digital (Coax): 0.5V OUTPUT IMPEDANCE Line Level: 100Ω Digital (Coax): 75Ω Support Datasheet Manual

The stunning control and authoritative power of the Michi M8 Monoblock Amplifier is the result of a perfect balance of science meets art delivering 1,080 watts of Class AB power into 8 ohms and an astounding 1,800 watts to the most demanding 4 ohm loudspeakers. The M8 is powered by a pair of custom engineered, low noise, in-house manufactured toroidal transformers supported by 4 British patented slit foil, high efficiency, low ESR bulk storage capacitors for impactful bass with exceptional control under extreme loading conditions. To achieve accuracy and its unsurpassed performance, the M8 is equipped with an array of 32 high current output transistors thus reducing the load on individual components and maintaining the crucial energy, rhythm and timing throughout the amplification stages. Musical expression and detailed refinement were further accomplished through acoustic tuning of all critical components and a balanced circuit design. A high resolution display adorns the front panel supporting a peak power meter or spectrum analyzer. With XLR and RCA inputs, 2 sets of custom Michi speaker binding posts, remote control and fully featured RS232 and Ethernet connections the M8 provides ultimate installation flexibility. Power amplification at its best in the most elegant of industrial designs. Features 1080 Watts of Robust Power Class AB amplifier design Patented British Bulk Storage Capacitors Massive power supply using dual toroidal transformers Balanced XLR inputs Includes remote control Specifications CONTINUOUS POWER OUTPUT 1080W/Ch (8Ω) 1800W/Ch (4Ω) TOTAL HARMONIC DISTORTION (THD) <0.018% FREQUENCY RESPONSE 20Hz - 20kHz (+0dB, -0.15dB) 10Hz - 100kHz (+0dB, -0.5dB) S/N RATIO (IHF "A" Weighted) 120dB GAIN Unbalanced (RCA): 34dB Balanced (XLR): 30dB DIMENSIONS (W × H × D) 485 × 238 × 465mm 19" × 9.375" × 18.25" FRONT PANEL HEIGHT 220mm (8.625") POWER REQUIREMENTS 230V, 50Hz POWER CONSUMPTION 1200W STANDBY POWER CONSUMPTION Normal: <0.5W Network Wakeup: <2W NET WEIGHT 59.1kg (130.3lbs.) BTU RATING (4Ω, 1/8th power) 3200 BTU/h INTERMODULATION DISTORTION (60Hz:7kHz, 4:1) <0.03% DAMPING FACTOR 200 SPEAKER IMPEDANCE 4Ω minimum INPUT SENSITIVITY Unbalanced (RCA): 1.85V Balanced (XLR): 3V INPUT IMPEDANCE Unbalanced (RCA): 12.5kΩ Balanced (XLR): 100kΩ Support Datasheet Manual Reviews & Awards Stereoplay - Apr. 2020 Stereo - Jan. 2020 About Rotel For over six decades Rotel has been engineering, manufacturing, and delivering audio products built to the highest standards of quality, with extraordinary performance and exceptional value. This Japanese family owned, and family operated business leverages the tradition and heritage of this 60-Year old icon brand supported by innovation and passion delivering products proud to wear the Rotel badge building our ever-growing extended Rotel family of customers including audiophiles, music lovers, musicians, recording artists and loyal fans. Welcome to Michi. Michi is a flagship series of products built on the history and heritage of Rotel. Michi represents over 55 years of experience coupled with the passion of a family business and ever-growing family of satisfied product owners. Acoustic Elevation. Sonic Evolution. Visual Perfection. Michi, because our reputation is personal.

The Michi P5 Control Amplifier delivers the ultimate performance in audio processing with a full complement of analog and digital source inputs. Over 3 years in the making, every aspect of the P5 has been carefully crafted including the power supply, circuit design and critical component selection to ensure the highest integrity of the audio signal eliminating unwanted noise and distortion. The Dual AKM 32-bit DACs feed the Class-A preamplifier circuit ensuring detail, accuracy and the highest musical fidelity while maintaining crucial rhythm and timing for all musical genre regardless of your listening style. These circuits are supported by an array of 17 independent voltage regulators driven from 2 custom designed and factory built toroidal transformers with low ESR smoothing capacitors to deliver ripple free current to all critical circuits. Accuracy and detail are essential in reproducing audio and equality important is delivering music that is enjoyable and entertaining. The P5 excels in all aspects building on over 55 years of audio design experience. The bespoke in-house manufacturing facility ensures this preamplifier is built to highest of quality standards allowing it to proudly wear the Michi logo. Automation and control system integration is easily supported with RS232 and Ethernet connections. The Michi P5 includes MQA (Master Quality Authenticated) technology, which enables you to play back MQA audio files and streams, delivering the sound of the original master recording. Features AKM premium 32-bit/ 768kHz Digital to Analog Converter Moving Coil and Moving Magnet phono stage input Bluetooth with apt-X and AAC Balanced XLR inputs and outputs Supports MQA Includes remote control Specifications TOTAL HARMONIC DISTORTION (THD) (20Hz–20kHz) 85dB Phono Input: >55dB TONE CONTROLS ±10dB at 100Hz / 10kHz COAX/OPTICAL DIGITAL INPUT SIGNALS LPCM (Up to 24-bit/192kHz) PC-USB USB Audio Class 1 (up to 24/96) USB Audio Class 2 (up to 32/384)* *Driver Installation Required DSD and DoP Support MQA Support Support Datasheet Manual Reviews & Awards Hi-Fi Choice - Oct. 2020 StereoNet - Sep. 2020 Hi-Fi News - May 2020 TED Publications - May 2020 Audio (Germany) - May 2020 Hifi&Musik - Apr. 2020 Audio Review n. 419 - Apr. 2020 Stereoplay - Apr. 2020 Audio (Poland) - Mar. 2020 Alpha-Audio - Jan. 2020 Stereo - Jan. 2020 About Rotel For over six decades Rotel has been engineering, manufacturing, and delivering audio products built to the highest standards of quality, with extraordinary performance and exceptional value. This Japanese family owned, and family operated business leverages the tradition and heritage of this 60-Year old icon brand supported by innovation and passion delivering products proud to wear the Rotel badge building our ever-growing extended Rotel family of customers including audiophiles, music lovers, musicians, recording artists and loyal fans. Welcome to Michi. Michi is a flagship series of products built on the history and heritage of Rotel. Michi represents over 55 years of experience coupled with the passion of a family business and ever-growing family of satisfied product owners. Acoustic Elevation. Sonic Evolution. Visual Perfection. Michi, because our reputation is personal.

Experience unrivaled audio quality with the Michi Q5 Transport DAC. This high-performance CD player features a premium CNC aluminum design CD Mechanism, an advanced ESS ES9028PRO DAC for precise sound, and versatile connectivity including 32-bit/384k Hz PC-USB and 24-bit/192k Hz coaxial and optical source inputs. Enjoy impeccable audio and the ultimate performance with the Michi Q5. Elevate your audio experience with the Michi Q5 Transport DAC, a state-of-the-art high performance CD player that combines cuttingedge technology with exceptional craftsmanship and unparalleled sound quality. The Michi Q5 features a top-loading CD mechanism constructed from premium CNC aluminum, ensuring durability and a sleek, modern look. The CD mechanism is mounted on a floating spring assembly to reduce unwanted vibrations and physically isolate the motor from sensitive electronic circuits. This design not only enhances the player’s aesthetic appeal but also provides a stable and precise platform for your CDs. At the heart of the Q5 lies a premium ESS ES9028PRO DAC, renowned for its high-fidelity audio conversion. This 8-channel DAC performs the critical digital to analog conversion dedicating 4 channels each to the left and right audio signal paths. The 4 times signal processing redundancy of the ESS Sabre DAC extracts further details of the audio buried deep within the recording presented on an expansive sound stage. The fully balanced, fully differential circuit design renders precision with an extremely low noise floor to the XLR and RCA analog outputs for pristine sound reproduction with minimal distortion. CD audio is also available via Coaxial and Optical Toslink connectors allowing the Q5 to function as a dedicated CD Transport. Dual in-house manufactured toroidal transformers isolate the digital and analog voltage supplies, significantly reducing noise and interference. Additionally, the CD drive motor voltage and current power supplies are electrically isolated from the audio signals, ensuring the quality and purity of sound is maintained and avoiding electronic motor noise leaking into the sensitive audio signals. In addition to a premium CD player, the Q5 features a wide range of audio inputs including PC-USB (up to 32-bit / 384kHz) with MQA and DSD 4X support, and 24-bit / 192kHz Coaxial and Optical inputs, making it compatible as a DAC for all of your favorite digital sources. The elegant front panel is void of clutter befitting a Michi product featuring a full-color TFT display capable of showcasing CD album artwork enhancing your listening experience with visual appeal. With the included Michi remote, the Q5 offers intuitive, seamless operation and control. RS232 and Ethernet ports provide integration with all popular automation systems ensuring you can manage your audio setup with ultimate ease. The Michi Q5 Transport DAC is designed for the discerning audiophile who demands the best in both performance and aesthetics. Its premium construction, exceptional audio quality, versatile connectivity, and advanced control options make it the ultimate CD player for your high-end audio system. Experience the elevation of audio engineering with the Michi Q5 Transport DAC. Features High Precision CD Mechanism Use as a CD player or DAC or CD Transport Roon Tested Supports MQA and MQA Studio Fully Balanced Differential XLR Outputs ESS ES9028PRO 32-bit 8-Channel Digital to Analog Converter Specifications TOTAL HARMONIC DISTORTION (THD) CD/Coaxial/Optical/PC-USB Input: 115 dB DYNAMIC RANGE >99 dB DIGITAL TO ANALOG CONVERTERS ESS ES9028PRO DAC CHANNEL BALANCE ± 0.5 dB CHANNEL SEPARATION >104 dB @ 10k Hz INTERMODULATION DISTORTION < 0.002% ANALOG OUTPUT LEVEL Unbalanced (RCA): 2.3 V, Balanced (XLR): 4.9 V ANALOG OUTPUT IMPEDANCE Unbalanced (RCA): 100 Ω, Balanced (XLR): 4k Ω INPUT SENSITIVITY 0 dBfs / 75 Ω COAX/OPTICAL DIGITAL INPUT SIGNALS LPCM (Up to 24-bit / 192k Hz) DIMENSIONS (W × H × D) 485 x 150x 452 mm / 19 x 6 x 17.75 " FRONT PANEL HEIGHT 132 mm (5.25") POWER REQUIREMENTS 230 V, 50 Hz POWER CONSUMPTION 25 W STANDBY POWER CONSUMPTION <0.5 W NET WEIGHT 23.5 kg (51.8 lbs.) Support Manual Datasheet

The Michi S5 Stereo Power Amplifier is a best in class linear amplifier delivering 500 watts of Class AB power in 8 ohm and over 800 watts to 4 ohm loads. The dual monoblock architecture is equipped with twin, custom engineered oversized, in-house manufactured 2,200 Volt Amp toroidal transformers in individual epoxy filled enclosures eliminating noise and vibration. A bank of 4 British patented bulk storage capacitors totalling 188,000uF delivers exceptional bass energy while maintaining precise detail and control to 32 high current output transistors ensuring effortless accuracy of the timing and rhythm under even the most difficult of load conditions. Audio performance must be engineered from product concept through production. This is evidenced in the S5 as the result of countless hours of engineering design reviews, critical component evaluation and sonic tuning. Accuracy at its best while delivering on a promise to ensure the audio provides entertainment deserving of the Michi logo. An elegant industrial design puts the finishing touch on this amplifier with a font panel color display and Michi exclusive custom high current 5-way rhodium plated binding posts. The included remote control provides easy setup and operation with RS232 and Ethernet connections supporting all popular control systems. Features 2 x 500 Watts of Robust Power Class AB amplifier design Patented British Bulk Storage Capacitors Massive power supply using dual toroidal transformers Balanced XLR inputs Includes remote control Specifications CONTINUOUS POWER OUTPUT 500W/Ch (8Ω) 800W/Ch (4Ω) TOTAL HARMONIC DISTORTION (THD) 65dB Support Datasheet Manual Reviews & Awards Hi-Fi Choice - Oct. 2020 StereoNet - Sep. 2020 Lyd&Blide - Jun. 2020 Hi-Fi News - May 2020 TED Publications - May 2020 Audio (Germany) - May 2020 Hifi&Musik - Apr. 2020 Audio Review n. 419 - Apr. 2020 Stereoplay - Apr. 2020 Audio (Poland) - Mar. 2020 Alpha-Audio - Jan. 2020 Stereo - Jan. 2020 About Rotel For over six decades Rotel has been engineering, manufacturing, and delivering audio products built to the highest standards of quality, with extraordinary performance and exceptional value. This Japanese family owned, and family operated business leverages the tradition and heritage of this 60-Year old icon brand supported by innovation and passion delivering products proud to wear the Rotel badge building our ever-growing extended Rotel family of customers including audiophiles, music lovers, musicians, recording artists and loyal fans. Welcome to Michi. Michi is a flagship series of products built on the history and heritage of Rotel. Michi represents over 55 years of experience coupled with the passion of a family business and ever-growing family of satisfied product owners. Acoustic Elevation. Sonic Evolution. Visual Perfection. Michi, because our reputation is personal.

Elegant, efficient, uncompromised. The Michi X3 Series 2 Integrated Amplifier combines 350 Watts of robust Class AB output power and an 8-Channel ESS SABRE Digital to Analog converter to deliver a refined and expansive performance. Analog RCA, XLR, Moving Magnet Phono, aptX™ HD Bluetooth, Coaxial, Optical, and PC-USB rendering MQA are all supported . The Michi X3 Series 2 Integrated Amplifier delivers an unparalleled listening experience rendering audio with exceptional accuracy, refinement and detail on an expansive soundstage, courtesy of 350 Watts of robust Class AB output power and an 8-Channel ESS SABRE ES9028PRO Digital to Analog converter. The elegant industrial design of the Michi X3 Series 2 is at home in any living space, and its 350 watts of Class AB output power pairs with nearly any loudspeaker. Analog, Digital, PC-USB (MQA, PCM, DSD), XLR Balanced, and wireless aptX™HD Bluetooth sources are all supported, and a Moving Magnet Phono Stage is included for vinyl lovers. Performance engineered, acoustically refined, and meticulously manufactured to be operated with ease by music lovers and audiophiles alike. Michi, expectations amplified. Features 2 x 350 Watts of robust power Class AB amplifier design Bluetooth with aptX and AAC 8-Channel ESS SABRE ES9028PRO Digital to Analog converter Balanced XLR inputs Specifications MAXIMUM POWER OUTPUT 350W/Ch (4Ω) CONTINUOUS POWER OUTPUT 200W/Ch (8Ω) TOTAL HARMONIC DISTORTION (THD) 55dB INPUT SENSITIVITY Line Level Inputs (RCA): 340mV, Line Level Inputs (XLR): 540mV, Phono Input (MM): 5.2mV INPUT IMPEDANCE Line Level Inputs (RCA): 100kΩ, Line Level Inputs (XLR): 100kΩ, Digital Inputs: 75Ω, Phono Input (MM): 47kΩ INPUT OVERLOAD Line Level Inputs (RCA): 3.5V, Line Level Inputs (XLR): 5.5V, Phono Input: 60mV PREOUT LEVEL 1.9V OUTPUT IMPEDANCE 100Ω TONE CONTROLS ±10dB at 100Hz / 10kHz COAX/OPTICAL DIGITAL INPUT SIGNALS SPDIF LPCM (Up to 24-bit/192kHz) PC-USB USB Audio Class 1 (up to 24-bit/96kHz) USB Audio Class 2 (up to 24-bit/384kHz)* *Driver installation required DSD and DoP support MQA and MQA Studio support Roon Tested support Support Datasheet Manual Reviews & Awards Hifi Choice - Apr. 2021 Hifi News - Apr. 2021 Hifi&Musik - Dec. 2020 About Rotel For over six decades Rotel has been engineering, manufacturing, and delivering audio products built to the highest standards of quality, with extraordinary performance and exceptional value. This Japanese family owned, and family operated business leverages the tradition and heritage of this 60-Year old icon brand supported by innovation and passion delivering products proud to wear the Rotel badge building our ever-growing extended Rotel family of customers including audiophiles, music lovers, musicians, recording artists and loyal fans. Welcome to Michi. Michi is a flagship series of products built on the history and heritage of Rotel. Michi represents over 55 years of experience coupled with the passion of a family business and ever-growing family of satisfied product owners. Acoustic Elevation. Sonic Evolution. Visual Perfection. Michi, because our reputation is personal.

The Michi X5 Integrated Amplifier is Performance Redefined delivering an astounding 600 Watts of Class AB power into 4 ohm speakers under even extreme loading conditions. The X5 is replete with inputs ensuring support of all popular audio sources including Analog, Digital, XLR, PC-USB with MQA rendering, apt-X Bluetooth, and selectable Moving Magnet or Moving Coil Phono Stage. The acoustic eminence of the X5 is achieved utilizing a perfect balance of innovation and critical engineering of every circuit, signal path and audio component ensuring the exquisite industrial design is surpassed only by breathtaking performance. Musical expression of the X5 is evidenced by the exceptional control of near limitless bass energy and essential clarity of the midrange and high frequencies. The X5 delivers true-to life audio reproduction ensuring meticulous accuracy of the musical timing with exacting spatial positioning be it a solo artist or full orchestral symphony. The X5 oversized, in-house manufactured toroidal transformer feeds 88,000uF of high efficiency bulk storage smoothing capacitors with isolated power supply feeds to all acoustically sensitive circuits eliminating unwanted noise or distortion further refining the audio. A front panel high-resolution graphic display is configurable to show operating status, 12 band Graphic EQ or Peak Power Meter. Front panel controls and included Michi remote control assure easy operation and configuration. Dual sets of Rhodium plated custom Michi speaker binding posts allow effortless connection to loudspeakers including bi-wire installations. RS232 and Ethernet connections allow simple integration with control systems. Features 2 x 600 Watts of robust power Bluetooth with aptX AKM premium 32-bit/768kHz Digital to Analog Converter Balanced XLR inputs Supports MQA Specifications CONTINUOUS POWER OUTPUT 600W/Ch (4Ω) 350W/Ch (8Ω) TOTAL HARMONIC DISTORTION (THD) 65dB INPUT SENSITIVITY Line Level Inputs (RCA): 380mV Line Level Inputs (XLR): 580mV Phono Input (MM): 5.7mV Phono Input (MC): 570 uV INPUT IMPEDANCE Line Level Inputs (RCA): 100kΩ Line Level Inputs (XLR): 100kΩ Digital Inputs: 75Ω Phono Input (MM): 47kΩ Phono Input (MC): 100Ω INPUT OVERLOAD Line Level Inputs (RCA): 12.5V Line Level Inputs (XLR): 12.5V Phono Input (MM): 197mV Phono Input (MC): 19mV PREOUT LEVEL 1V OUTPUT IMPEDANCE 470Ω TONE CONTROLS ±10dB at 100Hz / 10kHz COAX/OPTICAL DIGITAL INPUT SIGNALS SPDIF LPCM (Up to 24-bit/192kHz) PC-USB USB Audio Class 1 (up to 24/96) USB Audio Class 2 (up to 32/384) MQA, DSD and DoP support Support Datasheet Manual About Rotel For over six decades Rotel has been engineering, manufacturing, and delivering audio products built to the highest standards of quality, with extraordinary performance and exceptional value. This Japanese family owned, and family operated business leverages the tradition and heritage of this 60-Year old icon brand supported by innovation and passion delivering products proud to wear the Rotel badge building our ever-growing extended Rotel family of customers including audiophiles, music lovers, musicians, recording artists and loyal fans. Welcome to Michi. Michi is a flagship series of products built on the history and heritage of Rotel. Michi represents over 55 years of experience coupled with the passion of a family business and ever-growing family of satisfied product owners. Acoustic Elevation. Sonic Evolution. Visual Perfection. Michi, because our reputation is personal.

The RA-1572MKII Integrated Amplifier is an essential component for music lovers leveraging the best of Rotel’s analog and digital technologies bringing music to life with exceptional fidelity. The role of an integrated amplifier continues to evolve with the RA-1572MKII optimized in every aspect including the power amplifier delivering 120 Watts of robust Class AB output into 8 ohms, audio circuit design innovations, premium audiophile Digital to Analog Converter and a full complement of source inputs. As typical of Rotel amplifiers, the RA-1572MKII utilizes an in-house manufactured oversized toroidal transformer. The toroidal transformer’s shape helps prevent stray radiation patterns from corrupting audio signals as they pass through adjacent circuits. The transformer feeds a bank of 4 low ESR, high efficiency, T-Network slit-foil storage capacitors for deep, controlled bass energy. The RA-1572MKII support digital sources utilizing a Texas Instruments 32-bit/384kHz DAC with critically tuned output filter circuits rendering even the most subtle detail. The preamplifier circuits and linear amplifier gain stages have been custom engineered ensuring natural detail, agility and an immersive soundstage. Analog, digital, PC-USB supporting MQA, aptXTM and AAC wireless Bluetooth streaming, XLR Balanced and Moving Magnet Phono stage inputs ensures connection to your favorite sources. The RA-1572MKII is certified Roon Tested delivering the best experience using Roon software so you can just enjoy the music. The front panel includes a status display, source and volume controls, Speaker A-B selection for Zone 2, and 3.5mm headphone jack. Ethernet and RS232 connections allow seamless integration with control systems and software updates. Features 2 x 200 Watts of robust Class AB power, 4 Ohms Certified Roon Tested Supports MQA and MQA Studio Texas Instruments premium 32-bit/384kHz Digital to Analog Converter Wireless aptXTM and AAC Bluetooth Moving Magnet Phono input for turntable connection Specifications MAXIMUM POWER OUTPUT 200W/Ch (4Ω) CONTINUOUS POWER OUTPUT 120W/Ch (8Ω) TOTAL HARMONIC DISTORTION (THD) <0.018% FREQUENCY RESPONSE Line Level Inputs: 10Hz - 100kHz, ±0.5dB Digital Inputs: 10Hz - 90kHz, ±2dB Phono Input: 20Hz - 20kHz, ±0.5dB S/N RATIO (IHF "A" Weighted) Line Level Inputs: 100dB Digital Inputs: 100dB Phono Input: 80dB DIMENSIONS (W × H × D) 431 × 144 × 358mm 17" × 5.7" × 14.1" FRONT PANEL HEIGHT 3U / 132.6mm (5.25") POWER REQUIREMENTS 230V, 50Hz POWER CONSUMPTION 400W STANDBY POWER CONSUMPTION <0.5W NET WEIGHT 13.63kg (30.05lbs.) BTU RATING (4Ω, 1/8th power) 810 BTU/h INTERMODULATION DISTORTION (60Hz:7kHz, 4:1) <0.03% DAMPING FACTOR 300 INPUT SENSITIVITY Line Level Inputs (RCA): 270mV Line Level Inputs (XLR): 440mV Digital Inputs: 0 dBFs Phono Input (MM): 2.1mV INPUT IMPEDANCE Line Level Inputs (RCA): 100kΩ Line Level Inputs (XLR): 100kΩ Digital Inputs: 75Ω Phono Input (MM): 47kΩ INPUT OVERLOAD Line Level Inputs (RCA): 4V Line Level Inputs (XLR): 5.5V Phono Input: 32mV PREOUT LEVEL 1.5V OUTPUT IMPEDANCE 470Ω COAX/OPTICAL DIGITAL INPUT SIGNALS LPCM (Up to 24-bit/192kHz) PC-USB USB Audio Class 1 (up to 24-bit/192kHz) USB Audio Class 2 (up to 32-bit/384kHz)* *Driver installation required MQA and MQA Studio (up to 24-bit/384kHz ) Roon Tested Support Datasheet Manual Reviews & Awards StereoNET - Apr. 2021 About Rotel For over six decades Rotel has been engineering, manufacturing, and delivering audio products built to the highest standards of quality, with extraordinary performance and exceptional value. This Japanese family owned, and family operated business leverages the tradition and heritage of this 60-Year old icon brand supported by innovation and passion delivering products proud to wear the Rotel badge building our ever-growing extended Rotel family of customers including audiophiles, music lovers, musicians, recording artists and loyal fans.

Whether a seasoned audiophile or casual listener, the time has never been better to be a music lover. A near limitless supply of music is at our fingertips accessible via streaming, digital mediums, classic vinyl and more. Rotel has been designing and manufacturing high fidelity, high quality, high performance audio products for over 60 years accurately rendering audio with exceptional detail and stunning clarity. The RA-1592MKII proudly continues in the tradition and heritage of this iconic brand. The RA-1592MKII Integrated Amplifier includes circuit design innovations, optimization of audio signal paths and updates to critical power supply components delivering a breathtaking performance with dynamic rhythm and timing. Utilizing Rotel’s best-in-class preamplifier topology and award- winning power amplifier technology, the RA-1592MKII is a no- compromise, size-efficient, all-in-one integrated audio product. The RA-1592MKII delivers 200 Watts per channel into 8 ohms powered by Rotel’s in-house manufactured toroidal transformer feeding an array of slit-foil capacitors for rich, deep, controlled, bass energy. The RA-1592MKII supports your favorite sources including Analog, XLR, Digital, aptXTM and AAC wireless Bluetooth, PC-USB supporting MQA and 32-bit/384kHz PCM, and Moving Magnet Phono stage. Digital to Analog conversion utilizes a Texas Instruments premium DAC with precisely tuned output filter circuits delivering unprecedented acoustic detail, wide sound stage and exacting positioning. The RA-1592KII is certified Roon Tested delivering the best experience using Roon software so you can just enjoy the music. Selectable A-B speaker outputs, RS232, Ethernet and 12V triggers ensure seamless integration with control systems. Convenience, performance and value - the RA-1592MKII delivers. Features 2 x 350 Watts of robust Class AB power, 4 Ohms Certified Roon Tested Supports MQA and MQA Studio Texas Instruments premium 32-bit/384kHz Digital to Analog Converter Wireless aptXTM and AAC Bluetooth Moving Magnet Phono input for turntable connection Specifications MAXIMUM POWER OUTPUT 350W/Ch (4Ω) CONTINUOUS POWER OUTPUT 200W/Ch (8Ω) TOTAL HARMONIC DISTORTION (THD) 55dB INPUT SENSITIVITY Line Level Inputs (RCA): 340mV Line Level Inputs (XLR): 540mV Phono Input (MM): 5.2mV INPUT IMPEDANCE Line Level Inputs (RCA): 100kΩ Line Level Inputs (XLR): 100kΩ Digital Inputs: 75Ω Phono Input (MM): 47kΩ INPUT OVERLOAD Line Level Inputs (RCA): 3.5V Line Level Inputs (XLR): 5.5V Phono Input: 60mV PREOUT LEVEL 1.9V OUTPUT IMPEDANCE 100Ω TONE CONTROLS ±10dB at 100Hz / 10kHz COAX/OPTICAL DIGITAL INPUT SIGNALS SPDIF LPCM (Up to 24-bit/192kHz) PC-USB USB Audio Class 1 (up to 24/96) USB Audio Class 2 (up to 32/384)* *Driver installation required DSD and DoP support Support Datasheet Manual Reviews & Awards TONE Audio - Apr. 2021 About Rotel For over six decades Rotel has been engineering, manufacturing, and delivering audio products built to the highest standards of quality, with extraordinary performance and exceptional value. This Japanese family owned, and family operated business leverages the tradition and heritage of this 60-Year old icon brand supported by innovation and passion delivering products proud to wear the Rotel badge building our ever-growing extended Rotel family of customers including audiophiles, music lovers, musicians, recording artists and loyal fans.

Simplicity and performance meet in the Rotel RAS-5000, a component designed to fit into your lifestyle and elevate your entertainment experience. The RAS-5000 seamlessly integrates HDMI ARC (Audio Return Channel) for playback of video sound, and effortlessly streams from online sources to play your favorite music from Spotify Connect, Tidal Connect, Internet Radio, or any service available on your computer, tablet, or mobile device via Airplay 2, Google Cast, Roon, or aptXTM HD Bluetooth. The RAS-5000 is the perfect fusion of advanced audio technology coupled with modern convenience. In addition to streaming and HDMI ARC you’ll also enjoy a wide array of traditional source inputs including Coaxial, Optical and RCA Analog inputs. The PC-USB input supports PCM and native MQA and MQA Studio decoding. Digital music files up to 32-bit, 384kHz resolution are rendered with ultimate precision thanks to the premium ESS Digital to Analog converter, while the streamlined AMPLIFIED STREAMER RAS-5000 ARC connection between your TV and RAS-5000 ensures dynamic, high resolution sound from your favorite live sports, TV shows, movies, and games. Like all Rotel amplifiers, the RAS-5000 is constructed around a massive linear power supply featuring a custom toroidal transformer, which allows the RAS-5000 to deliver a staggering 220 watts of Class AB power into 4 ohms. The overengineered power supply delivers ultralow-noise power to all critical components and robust current to the amplifier output transistors to deliver deep, controlled bass energy with exceptional fidelity. The sleek RAS-5000 is available in both stylish black and sophisticated silver colors to blend seamlessly to any décor, while its user-friendly interface ensures effortless operation. Enhance and simplify your home entertainment experience without compromise today with the Rotel RAS-5000 and immerse yourself in sound. Features 2 x 220 Watts of robust Class AB power, 4 Ohms Certified Roon Ready Supports MQA and MQA Studio ESS premium 32-bit Digital to Analog Converter Wireless aptXTM and AAC Bluetooth Specifications POWER OUTPUT 220 Watts / ch (4 Ohms), 140 Watts / ch (8 Ohms) TOTAL HARMONIC DISTORTION (THD) <0.03% FREQUENCY RESPONSE Line Level Inputs: 10Hz - 100kHz, ±0.5dB, Digital Inputs: 10 Hz – 70k Hz, (±3 dB, MAX) S/N RATIO (IHF "A" Weighted), Line Level Inputs: 103dB, Digital Inputs: 105dB DIMENSIONS (W × H × D) 431 x 144 x 425 mm / 17” x 5 7/8” x 16” FRONT PANEL HEIGHT 132.6 mm / 5 1/4” POWER REQUIREMENTS 230V, 50Hz POWER CONSUMPTION 380W STANDBY POWER CONSUMPTION <0.5W NET WEIGHT 15.7 kg, 34.6 lbs BTU RATING (4Ω, 1/8th power), 1027 BTU/h INTERMODULATION DISTORTION (60 Hz : 7k Hz, 4:1), <0.03% DAMPING FACTOR 290 INPUT SENSITIVITY Line Level Inputs: 0.78mV, Digital Inputs: -8dBfs INPUT IMPEDANCE Line Level Inputs:46k Ohms, Digital Inputs: 75 Ohms INPUT OVERLOAD Line Level Inputs: 4.1V TONE CONTROLS ±10dB at 100Hz / 10kHz HDMI Support eARC function COAX/OPTICAL DIGITAL INPUT SIGNALS SPDIF LPCM (Up to 24-bit/192kHz) PC-USB USB Audio Class 2.0 (up to 24-bit/384kHz)*Driver installation required. MQA and MQA Studio (up to 24-bit/384kHz), Roon Ready Support Datasheet Manual About Rotel For over six decades Rotel has been engineering, manufacturing, and delivering audio products built to the highest standards of quality, with extraordinary performance and exceptional value. This Japanese family owned, and family operated business leverages the tradition and heritage of this 60-Year old icon brand supported by innovation and passion delivering products proud to wear the Rotel badge building our ever-growing extended Rotel family of customers including audiophiles, music lovers, musicians, recording artists and loyal fans.

The RB-1552MKII is a 130 watt per channel class A/B amplifier. It is engineered to be powerful and robust, yet able to extract every last nuance out of even the most complex musical score. Rotel engineering’s fanatical attention to detail means the sum is greater than the parts, what we call our Balanced Design Concept*. Each aspect of design is carefully considered holistically to result in maximum audio performance; from the selection of an over-sized power supply featuring a highly efficient, low magnetic field toroidal transformer to multiple, high-current bipolar output transistors. Circuit topology is planned, implemented, evaluated, and adjusted to achieve optimum results. The RB-1552MKII features independent left and right power rectification stages and decoupling, and is essentially a mono block design. Further evidence of design over- spec is in the selection of premium “slit-foil” capacitors, which provide plenty of reserve energy for extremely dynamic audio passages and are able to quickly replenish themselves due to the nature of their unique design. Input options are balanced XLR or unbalanced RCA connectors. The RB-1552MKII stereo amplifier has been engineered to provide high-resolution audio performance, yet it is very affordable, as has been the tradition with Rotel electronics for over 50 years. Features 2 x 130 Watts of Robust Power Class AB amplifier design High-quality slit foil Capacitors made in Britain Rack ears included Balanced XLR inputs Specifications CONTINUOUS POWER OUTPUT 130W/Ch (All channels driven, 8Ω) TOTAL HARMONIC DISTORTION (THD) (20Hz–20kHz) <0.03% FREQUENCY RESPONSE 10Hz - 100kHz ±0.5dB S/N RATIO (IHF "A" Weighted) 120dB GAIN RCA: 26.5dB XLR: 22.5dB DIMENSIONS (W × H × D) 431 × 144 × 339mm 17" × 5.7" × 13.4" FRONT PANEL HEIGHT 3U / 132.6mm (5.25") POWER REQUIREMENTS 230V, 50Hz POWER CONSUMPTION 400W STANDBY POWER CONSUMPTION 0.5W NET WEIGHT 12.4kg (27lbs.) BTU RATING (4Ω, 1/8th power) 905 BTU/h INTERMODULATION DISTORTION (60Hz:7kHz, 4:1) <0.03% DAMPING FACTOR 450 SPEAKER IMPEDANCE 4Ω minimum INPUT SENSITIVITY Line Level Inputs (RCA): 1.5V Line Level Inputs (XLR): 2.5V INPUT IMPEDANCE Line Level Inputs (RCA): 12kΩ Line Level Inputs (XLR): 100kΩ Support Datasheet Manual Reviews & Awards The Absolute Sound - April 2014 About Rotel For over six decades Rotel has been engineering, manufacturing, and delivering audio products built to the highest standards of quality, with extraordinary performance and exceptional value. This Japanese family owned, and family operated business leverages the tradition and heritage of this 60-Year old icon brand supported by innovation and passion delivering products proud to wear the Rotel badge building our ever-growing extended Rotel family of customers including audiophiles, music lovers, musicians, recording artists and loyal fans.

Rotel’s largest stereo amplifier at 200 watts per channel provides the massive current to drive the very largest hifi systems effortlessly. And like its smaller brother, the RB-1582MKII has been designed to excel at resolving the subtle details in music as well as supplying the brawn required for extremely dynamic passages. It is able to achieve this difficult dual requirement because of the meticulous attention paid to circuit design and parts selection. The RB-1582 MKII ‘s high-end performance begins with an extremely large toroidal transformer combined with a total of 60,000uF storage capacity in special “slit foil” capacitors to provide completely stable power to the output stage. Slit foil capacitors have the ability to charge and discharge extremely quickly, thereby ensuring signal fidelity during orchestral crescendos or repetitive kick-drum impacts, for example. Both left and right channel construction are laid out in a mono block design (after the toroidal transformer) and all grounding is terminated in a star pattern on a copper grounding plate to ensure low signal to noise. The output stage is a discrete design that consists of 10 high current bipolar transistors per channel. Input options consist of both balanced XLR and unbalanced RCA connectors. The RB-1582 stereo power amplifier is yet another outstanding example of Rotel’s Balanced Design Concept and will form the heart of a very impressive stereo or home theater system for years to come. Features 2 x 200 Watts of Robust Power Class AB amplifier design High-quality slit foil Capacitors made in Britain Massive power supply using dual toroidal transformers Balanced XLR inputs Specifications CONTINUOUS POWER OUTPUT 200W/Ch (All channels driven, 8Ω) TOTAL HARMONIC DISTORTION (THD) (20Hz–20kHz) <0.03% FREQUENCY RESPONSE 10Hz - 100kHz ±0.5dB S/N RATIO (IHF "A" Weighted) 116dB GAIN RCA: 26.5dB XLR: 22.5dB DIMENSIONS (W × H × D) 431 × 144 × 407mm 17" × 5.7" × 16" FRONT PANEL HEIGHT 3U / 132.6mm (5.25") POWER REQUIREMENTS 230V, 50Hz POWER CONSUMPTION 550W STANDBY POWER CONSUMPTION 0.5W NET WEIGHT 17.6kg (39lbs.) BTU RATING (4Ω, 1/8th power) 1104 BTU/h INTERMODULATION DISTORTION (60Hz:7kHz, 4:1) <0.03% DAMPING FACTOR 800 SPEAKER IMPEDANCE 4Ω minimum INPUT SENSITIVITY Line Level Inputs (RCA): 1.9V Line Level Inputs (XLR): 3.0V INPUT IMPEDANCE Line Level Inputs (RCA): 12kΩ Line Level Inputs (XLR): 100kΩ Support Datasheet Manual Reviews & Awards Sound Stage Access - Feb. 2014 About Rotel For over six decades Rotel has been engineering, manufacturing, and delivering audio products built to the highest standards of quality, with extraordinary performance and exceptional value. This Japanese family owned, and family operated business leverages the tradition and heritage of this 60-Year old icon brand supported by innovation and passion delivering products proud to wear the Rotel badge building our ever-growing extended Rotel family of customers including audiophiles, music lovers, musicians, recording artists and loyal fans.

Power - refined, detailed, and plenty of it. Rotel’s new Class AB stereo power amplifier is rated at 350 watts per channel into 8 ohms both channels driven. That is a lot of power, but larger listening rooms or less sensitive loudspeaker designs require it to bring out the best possible performance and attain realistic audio dynamics. The impressive capabilities of this amplifier begin with a solid foundation consisting of twin, massive toroidal transformers custom made by Rotel. These transformers are just part of a rock- solid power supply that includes eight special British made BHC capacitors, known for their low loss and quick response times. These components will continue to supply all of the voltage and current requirements needed, even under the most difficult load conditions. But power unrefined has never been a Rotel design goal. Every aspect of circuit design has been carefully considered and each component has been rigorously selected after extensive listening sessions The circuit topography has been laid out in a true monoblock design ensuring maximum signal separation and improved stereo imaging. Features include : XLR Balanced and RCA input connections, two pair of 5-way speaker binding posts, 12-volt trigger control, thermal protection circuitry, overcurrent, over-voltage protection circuitry, dual staged power on relay to reduce surge current and extend longevity, and a detachable IEC power cord all in a 5 U chassis with included rack ears. The RB-1590 has been designed for the most discerning audio enthusiast and will provide the highest levels of audio performance. Features 2 x 350 Watts of Robust Power Class AB amplifier design High-quality slit foil Capacitors made in Britain Massive power supply using dual toroidal transformers Balanced XLR inputs Specifications CONTINUOUS POWER OUTPUT 350W/Ch (All channels driven, 8Ω) TOTAL HARMONIC DISTORTION (THD) (20Hz–20kHz) 50dB Support Datasheet Manual Reviews & Awards HomeTheaterReview.com - Mar. 2016 Audio Video Revolution - Feb. 2016 Secrets of Home Theater and High Fidelity - Jan. 2016 AVSForum - Jan. 2016 Technofile.com - Nov. 2015 TheaterByte.com - Sept. 2015 About Rotel For over six decades Rotel has been engineering, manufacturing, and delivering audio products built to the highest standards of quality, with extraordinary performance and exceptional value. This Japanese family owned, and family operated business leverages the tradition and heritage of this 60-Year old icon brand supported by innovation and passion delivering products proud to wear the Rotel badge building our ever-growing extended Rotel family of customers including audiophiles, music lovers, musicians, recording artists and loyal fans.

Affordable high-end begins with Rotel’s RC-1572MKII Preamplifier including multiple acoustic upgrades and refinements processing your favorite analog and digital sources to an even higher level of performance in stunning clarity with a natural, enveloping sound stage. As an essential component in a Hi-Fi audio stack the RC- 1572MKII's precision engineering begins with Rotel’s ultra-low noise power supply including a large, in-house manufactured toroidal transformer. The transformer design reduces stray radiated emissions and feeds a bank of slit-foil, low ESR capacitors delivering stable current to all sensitive circuits reducing noise and distortion with an ultra-quiet noise floor. A premium Texas Instruments 32-bit Digital to Analog converter (DAC) renders the digital sources supported by custom tuned, proprietary external output filters ensuring the audio is effortlessly presented with exceptional dynamic detail and musical expression. Analog, Digital, XLR, aptX TM and AAC Wireless Bluetooth and Moving Magnet Phono Stage inputs ensure connection to your favorite music sources. Digital media files are supported via a 32-bit/384kHz PC-USB connection supporting MQA and is fully certified Roon Tested for graceful access to the near limitless catalog of online music. The RC-1572MKII is easy to operate using the included remote control and front panel display. Automatic power controls, signal sensing, fixed volume settings and tone adjustments optimize customization settings. RCA, XLR and subwoofer outputs are provided for installation flexibility. Ethernet and RS232 ensure simple integration with control systems and software updates. Bring your CD’s, Digital Files and Vinyl allowing the RC-1572MKII to bridge generations of music and music lovers. Features Certified Roon Tested Supports MQA & MQA Studio Texas Instruments premium 32-bit/ 384kHz Digital to Analog Converter Moving Magnet phono stage input for Turntable connection Wireless Bluetooth with aptX and AAC Balanced XLR inputs and outputs Specifications TOTAL HARMONIC DISTORTION (THD) (20Hz–20kHz) 85dB Line Level Inputs (XLR): >75dB Phono Input: >85dB TONE CONTROLS ±10dB at 100Hz / 10kHz PREAMPLIFIER OUTPUT LEVEL 1.44 V (at - 20 dB) COAX/OPTICAL DIGITAL INPUT SIGNALS LPCM (Up to 24-bit/192kHz) PC-USB USB Audio Class 1 (up to 24-bits/96kHz) USB Audio Class 2 (up to 32-bits/384kHz)* *Driver Installation Required MQA and MQA Studio (up to 24-bits/384kHz) Roon Tested Support Datasheet Manual Reviews & Awards What Hifi - May 2021 SoundStage - May 2021 The Absolute Sound - May 2021 AudioXpress - May 2021 AV Forums - May 2021 CE Pro - May 2021 Dagogo- May 2021 HD Guru - May 2021 Hifi Pig - May 2021 Home Cinema Magazine - May 2021 SECRETS - May 2021 Parttime Audiophile - May 2021 Positive Feedback - May 2021 Tech Week Mag - May 2021 YouTube/AV Atmos - May 2021 About Rotel For over six decades Rotel has been engineering, manufacturing, and delivering audio products built to the highest standards of quality, with extraordinary performance and exceptional value. This Japanese family owned, and family operated business leverages the tradition and heritage of this 60-Year old icon brand supported by innovation and passion delivering products proud to wear the Rotel badge building our ever-growing extended Rotel family of customers including audiophiles, music lovers, musicians, recording artists and loyal fans.

Reference audio systems deserve reference audio equipment. The Rotel RC-1590MKII is exactly that -- a reference preamplifier rending analog and digital sources with natural expression in a wide and open sound stage in stunning clarity. The heart of the RC-1590MKII begins with the power supply featuring dual in-house manufacture toroidal transformers. The transformers are physically and electrically isolated supplying dedicated analog and digital supply voltages to all critical circuits through low ESR slit-foil capacitors eliminating unwanted distortion and an extremely low noise floor. Digital source inputs are processed utilizing an audiophile grade Texas Instruments 32-bit/384kHz Digital to Audio Converter (DAC) with custom engineered, proprietary acoustically tuned external output filter circuits rendering even the finest details with exceptional clarity and exact positing. Analog signal paths feature DIRECT-PATH bypass modes eliminating unnecessary circuits maintaining signal integrity and further eliminating unwanted noise and distortion drawing you even closer and immersing you in the music. The RC-1590MKII supports a full array of inputs ensuring connection to your favorite sources including a Moving Magnet Phono input for vinyl lovers, Analog, Digital, XLR Balanced, high quality aptX TM and AAC wireless Bluetooth, and PC-USB (32-bit/384kHz) supporting MQA unfolding and rendering as well as certified Roon Tested. Dual RCA and XLR output connection provide the ultimate flexibility including bi-amplification installations. A subwoofer output is also included. The RC-1590MKII proudly continues Rotel’s 60-year legacy and heritage with our ongoing promises of performance, value, and unwavering commitment to quality. Authentic, engaging, and spacious – the RC-1590MKII proudly represents this iconic brand. Features Certified Roon Tested Supports MQA & MQA Studio Texas Instruments premium 32-bit/ 384kHz Digital to Analog Converter Moving Magnet phono stage input for Turntable connection Wireless Bluetooth with aptX and AAC Balanced XLR inputs and outputs Specifications TOTAL HARMONIC DISTORTION (THD) (20Hz–20kHz) 85dB Line Level Inputs (XLR): >75dB Phono Input: >85dB TONE CONTROLS ±10dB at 100Hz / 10kHz PREOUT LEVEL 1.65 V (at - 20 dB) COAX/OPTICAL DIGITAL INPUT SIGNALS LPCM (Up to 24-bit/192kHz) PC-USB USB Audio Class 1 (up to 24-bit/96kHz) USB Audio Class 2 (up to 32-bit/384kHz) *Driver installation required MQA and MQA Studio (up to 24-bit/384kHz ) Roon Tested Support Datasheet Manual Reviews & Awards SECRETS - May 2021 What Hifi - May 2021 SoundStage - May 2021 The Absolute Sound - May 2021 AudioXpress - May 2021 AV Forums - May 2021 CE Pro - May 2021 Dagogo- May 2021 HD Guru - May 2021 Hifi Pig - May 2021 Home Cinema Magazine - May 2021 SECRETS - May 2021 Parttime Audiophile - May 2021 Positive Feedback - May 2021 Tech Week Mag - May 2021 YouTube/AV Atmos - May 2021 About Rotel For over six decades Rotel has been engineering, manufacturing, and delivering audio products built to the highest standards of quality, with extraordinary performance and exceptional value. This Japanese family owned, and family operated business leverages the tradition and heritage of this 60-Year old icon brand supported by innovation and passion delivering products proud to wear the Rotel badge building our ever-growing extended Rotel family of customers including audiophiles, music lovers, musicians, recording artists and loyal fans.

Since 1982, when the CD was introduced, Rotel has been refining technology and evolving circuitry to bring you extraordinary sound from the familiar silver disc. As most music lovers have a substantial collection of compact discs, a high quality CD player is still an important part of most music systems. The RCD-1572, the outstanding CD player in Rotel‘s 15 series, focuses careful refinements to reveal even the most subtle nuances buried in a CD’s pit spiral. The RCD-1572 elevates performance by utilizing a purpose designed and built CD mechanism along with other circuit refinements. One of the RCD-1572’s most important features is the Wolfson WM8740 digital filter/stereo digital-to-analog converter. Originally developed for high resolution sources, it is the product of extensive research and real world testing and processes digital signals up to 24-bits in length at sampling rates from 8 kHz to 192 kHz. While word lengths and sampling speed may seem excessive for CDs delivering data at far lower rates, this high speed facility adds reserve capability to ensure proper reproduction under all circumstances. As the most crucial link between a CD’s digital data and the analog world in which we listen, this converter boasts significant attributes in addition to its superb high resolution capabilities. The post-converter analog circuitry benefits from Rotel‘s decades- long experiences in crafting the finest sounding pathway from the DAC’s internal output to RCA and XLR rear panel connectors that bridge the gap between the RCD-1572 and down-stream components. All circuit components – resistors, capacitors, inductors – are chosen only after their positive contribution to sound quality were quantified and verified qualitatively by extensive listening sessions. All of these circuits draw on a power supply based on an oversized custom Rotel-designed and precision-manufactured toroidal power transformer that, in turn, feeds precise rectifiers, tight- tolerance voltage regulators, and advanced Slit-Foil low-ESR storage capacitors, all globally sourced to ensure musically accurate operation under even the most demanding conditions. This is all part of Rotel’s long-proven Balanced Design Concept. It’s yet another way of assuring you that the RCD-1572 evidences a level of attention that will make it part of your reference-level music system for years to come. Features Wolfson premium 24-bit/192kHz Digital to Analog Converter iOS control App (requires connection to 15 Series RA/RC models) Supports MP3 playback Includes remote control Balanced XLR outputs Specifications TOTAL HARMONIC DISTORTION (THD) 0.002% @ 1kHz FREQUENCY RESPONSE 20Hz - 20kHz ±0.5dB S/N RATIO (IHF "A" Weighted) >118dB DYNAMIC RANGE >99dB DIGITAL TO ANALOG CONVERTERS Wolfson 24-bit/192kHz CHANNEL BALANCE ±0.5dB CHANNEL SEPARATION >115dB @ 10kHz DIMENSIONS (W × H × D) 431 × 104 × 320mm 17" × 4" × 12.6" FRONT PANEL HEIGHT 2U / 88.1mm (3.5") POWER REQUIREMENTS 230V, 50Hz POWER CONSUMPTION 15W STANDBY POWER CONSUMPTION <0.5W NET WEIGHT 6.7kg (15lbs.) BTU RATING 33 BTU/h OUTPUT LEVEL Unbalanced (RCA): 2.2V Balanced (XLR): 4.4V Digital (Coax): 0.5V OUTPUT IMPEDANCE Unbalanced (RCA): 100Ω Balanced (XLR): 200Ω Digital (Coax): 75Ω Support Datasheet Manual
