Volumio Rivo Plus Digital Streaming Transport

The Rivo Plus builds on the acclaimed Rivo model, now featuring a dedicated ASIC for enhanced S/PDIF and AES-EBU outputs and upgraded MEMS clocks in the USB HUB IC. This delivers pure digital sound and seamless connectivity for audiophiles.

The Rivo+ is the enhanced version of our award-winning Rivo digital transport. Engineered based on user feedback, Rivo+ elevates the already excellent qualities of the original.

Key upgrades include a dedicated ASIC for cleaner S/PDIF and AES-EBU outputs, improved MEMS clocks for lower jitter, I2S over HDMI connectivity for compatible high-end DACs, and a 12V trigger to power on/off other components.

If you demand the pinnacle of digital transport performance, the Rivo+ is the solution.

The Rivo+ features a dedicated ASIC to generate the S/PDIF and AES-EBU output signals, offloading this crucial task from the CPU. This specialized integrated circuit is designed to produce these digital output signals with uncompromising precision, free from any potential interference or jitter introduced by the main processor.

Powering this dedicated ASIC is a high-quality MEMS (Micro-Electro-Mechanical Systems) clock, which provides an exceptionally stable and low-jitter timing reference. Coupled with low-noise voltage regulators, this enhancement to the RIVO+ ensures the output signals maintain the utmost purity and refinement.

Upgraded MEMS clocks in the USB HUB IC enhance reclocking and signal integrity for Rivo+ especially when connected to the USB DAC port. This delivers exceptional jitter and frequency stability, reducing susceptibility to temperature changes and aging for consistently high-quality audio output.

Features

• Upgraded MEMS clocks in the USB HUB IC enhance reclocking and signal integrity at the USB DAC port, ensuring superior jitter stability and consistent audio quality
• I2S/DSD over HDMI interface offers optimal sonic performance for some external DACs compared to S/PDIF, AES-EBU, and USB
• Your DAC is receiving the purest and most error-free USB signal, thanks to its proprietary error correction and reclocking technology.
• RIVO lets you stream from your favorite music services such as Spotify, Tidal and Qobuz.
• Easy Setup - Getting started just takes a couple of minutes with the Volumio official iOS and Android apps
• Roon Ready
• Made in Italy

Specifications

• Digital Coaxial S/PDIF Audio Output, up to PCM 192kHz/24bit and DSD64 via DoP
• Digital AES/EBU Audio Output, up to to PCM 192kHz/24bit and DSD64 via DoP
• Digital I2S over HDMI Output Audio Output, up to PCM 768kHz/32bit and DSD256
• USB Output Audio Output, up to PCM 768kHz/32bit and DSD256 (via USB DAC)
• USB DAC Port 1x USB 2.0
• USB 1x USB 3.0, 1x USB 2.0
• LAN Gigabit 10/100/1000M
• Wireless Wi-Fi 802.11a/b/g/n/ac, 2X2 MIMO with RSDB
• Bluetooth 5.0
• Supported Formats DSD, WAV, FLAC, Alac, Aac, Vorbis, Cue, Mp3 and others
• UPNP DLNA Renderer with Open Home support
• Supported Services Airplay via Shairport Sync, Spotify & Spotify Connect, TIDAL & TIDAL Connect, QOBUZ
• Available Plugins Youtube, Squeezelite, Radio Paradise, Podcasts, Pandora, Fusion DSP, Roon Bridge, Soundcloud, Mixcloud
• CPU Amlogic S905D3, Quad Core 1.9 GHz
• RAM 2 GB DDR4
• Internal Storage 16 GB EMMCz
• Power Supply 5V, 3A
• Designer Design Narratives Ltd.
• Weight 2.25 kg
• Dimensions 27x15x5 cm
