Plixir Elite BDC MKII Balanced DC Power Supply
Taxes & Shipping Included
The PLiXiR Elite BDC MKII is a premium linear power supply that offers increased capacitance, reduced noise levels, and refined dynamic response. Designed with either one or two outputs, it prioritizes audio purity and seamless system integration. Manufactured in Singapore using high-quality components housed in a sturdy aluminum chassis, this power supply ensures outstanding stability and clarity for superior audio performance.
Experience upgraded performance with the PLiXiR Elite BDC MKII. Building on insights from our flagship Statement BDC, the Elite MKII features increased capacitance and an advanced layout with our proprietary Star+Ground plane design. These improvements result in an even lower noise floor, stronger dynamics, and greater sonic depth. This model introduces a simplified selection with 1-output (3A) or 2-output (5A) configurations, making it easier to match your system needs.
A balanced AC power design and a two-stage voltage regulation system work in tandem to remove ground loop and diode noise while minimizing interference between connected equipment. Every Elite BDC MKII is hand-assembled in Singapore, with PCB design, tuning, and final sonic signature personally overseen by our founder, James Soh. The rigid, single-piece aluminum chassis provides structural integrity and excellent vibration control, while doubling as an effective heat sink. With premium components throughout—ultra-low-impedance capacitors, high-current connectors, and high-purity copper wiring—you’ll enjoy a sound that’s neutral, refined, and precise.
Casing
Ultra rigid 1 piece aluminum body (min 5mm thick) body construction with 5mm bottom plate and 3mm top cover. This costly design provides the best vibration isolation possible with the least amount of joints. The casing doubles as the heat sink for the power supply, completing the elegant design.
Premium Components
Selected premium components including ultra-low-impedance capacitors, high-current connectors and high-purity copper cables. All chosen for a neutral and low noise sound.
Handcrafted
All PLiXiR products are handcrafted in Singapore. The ability to control all aspects of the PCB and product assembly allow us to fully optimise the performance and sound for all PLiXiR products. Each product is uniquely made. No cookie cutter process which focuses on production quantity but sacrifice performance is allowed here. We exist to make good products, not more products. The final tuning is done by James Soh, the founder, for the PLiXiR sound.
Specifications
- Output Current: Less than 1mVrms residual noise at DC ouput. Output Current available in 3 / 5 Amps current continuous.
- Input/Output Voltage: Input voltage: 230 Vac Output voltage: 5Vdc, 7.5Vdc, 9Vdc, 12Vdc, 15Vdc and 19Vdc
- Casing Finish: Black anodized, sandblasted aluminum
- Weight: 4.2kg (3A), 4.5kg (5A)
- Dimensions (in mm): 240 x 160 x 70 (3A), 240 x 160 x 79 (5A)
- (3A): 1 piece x 1 meter PLiXiR Elementa DC Power Cable with your choice of 2.1mm or 2.5mm DC plug. (5A): 2 pieces x 1 meter PLiXiR Elementa DC Power Cable with your choice of 2.1mm or 2.5mm DC plug.
