Matrix Audio CAT6A Audio-grade Network Cable
Taxes & Shipping Included
Experience the full potential of your music with the Matrix Audio CAT6A Network Patch Cord. This audiophile Ethernet cable is designed specifically for use with Matrix Audio music streamers, connecting them to network switches or routers for optimal sound transport. Constructed with the highest quality materials, this cable guarantees a reliable and high-quality medium for transmitting digital audio data. Don't settle for less when it comes to the path of your music.
Delivering true sound, crafted for music
Matrix Audio uses multi-core cables as the material of this network cable, which are different from traditional single-core cables. They consist of four pairs of multi-core wires twisted together. Each core wire contains seven strands of 0.16mm OFC. Each wire pair is individually shielded with aluminum foil. The outer layer is a second shielding layer composed of tin-plated copper wire mesh, which effectively isolates internal crosstalk and external interference, easily build your 10 Gigabit Ethernet.
Flexible connection, uncompromised speed
Taking advantage of the soft properties of multi-core cables, Matrix Audio's network cables maintain a flexible structure while meeting the 10 Gigabit Ethernet speed standard. This prevents the rigid cable body from exerting pressure on the network interface of the device, avoiding long-term issues such as poor contact or even damage to the network interface.
Exquisite in detail, achieving quality
The RJ45 connector adopts a fully shielded metal shell plug that meets the Cat.6A 10 Gigabit speed standard. The pins of the plug are plated with 50µm gold, resulting in extremely low contact resistance. The internal PCB uses high-frequency FR-4 material, providing a stable transfer impedance, fully meeting the demands of high-resolution audio stream over the network.
Features
- Seven strands of OFC wire in one core wire
- Four pairs of aluminum foil shielding
- Tin-plated copper wire mesh
- Flame retardant PVC cover
- Nylon braided sleeve
- High-frequency FR-4 PCB
- Pins with 50pm gold-plated
Specifications
- Diameter 8mm (Including nylon braided sleeve)
- Pinouts EIA/TIA568B
- Transfer rate 10Gbps
- Transfer bandwidth 500MHz
