Lumin T3 - Hi-Res Network Music Streamer DAC Preamplifier

The Performance Sweet Spot.  The first LUMIN with a DAC to feature our all-new processing system. Providing increased capacity and resampling flexibility. LUMIN T3 combines our new-for-2022 processing system, solid CNC-panel construction and X1 technology to deliver maximum price/performance.

Builds on the massive success of LUMIN T2

Completely new processing hardware and software deliver improved features and increased resampling flexibility while retaining all the musicality that was noted in so many outstanding T2 reviews. Among the key hardware features carried over from T2 are the Dual ES9028Pro SABRE DACs featuring dual-mono operation. The new model is also finished in a new silky surfacing process taken from our high-end P1 that is less susceptible to finger marks and easier to clean.

• Completely new hardware and software provide a new foundation for LUMIN
• Increased processing power and storage capacity provide greater resampling flexibility and future-proofing.

Precision analogue output stage

• Analogue buffer includes LUMIN X1 technology
• Dual-mono circuitry throughout
• Ultra-low-noise and high dynamic range

CNC chassis construction

• The thick CNC panelled construction offers upgraded structural rigidity and sheilding compared to the D2
• CNC milling techniques from LUMIN X1 provide the high-end LUMIN family aesthetic

All the usual LUMIN refinements

• From MQA to DSD, FLAC to WAV, LUMIN can play all the high-resolution formats you could ever want
• Native support for TIDAL, Qobuz, Spotify and AirPlay-compatible, giving you access to tens of millions of songs
• The unique and intuitive LUMIN App described as "the most convenient interface in existence" by TINMAN
• LUMIN programme of continuous development that has seen Roon, MQA, and Spotify support added in 2017 alone.

Features

• Features our all-new processing system
• Increased capacity for future updates
• Faster processor provides greater resampling flexibility
• New surface finish taken from the high-end P1
• Dual ES9028Pro SABRE DAC featuring dual-mono operation
• Upsampling and downsampling to every supported format up to DSD256/PCM384
• USB digital audio output
• Leedh Processing Volume control
• Roon Ready, Spotify Connect, MQA, TIDAL, TIDAL Connect, Qobuz, TuneIn and AirPlay-compatible

Specifications

• DSD SUPPORT:

  • Up to DSD512 22.6MHz, 1-bit

• PCM SUPPORT:

  • Up to 384kHz, 16–32-bit, Stereo

• ANALOG OUTPUT STAGE:

  • Dual ESS SABRE³² ES9028Pro DAC chips
  • Fully balanced layout with high-quality components
  • Completely redesigned analogue buffer includes audiograde output capacitor and ultra-low-noise and high dynamic range
  • Discreet clock system for precision timing
  • Precision 32-bit internal digital volume

• UPSAMPLING RATES & BIT DEPTHS:

  • DSD256 upsampling option for all files
  • PCM 384kHz upsampling option for all files

• DIGITAL OUTPUT STAGE:

  • USB:

    • Native DSD512 support
    • PCM 44.1–384kHz, 16–32-bit, Stereo

  • BNC SPDIF:

    • PCM 44.1kHz–192kHz, 16–24-bit
    • DSD (DoP, DSD over PCM) 2.8MHz, 1-bit

• POWER SUPPLY:

  • Internal 100–240V AC auto-ranging
  • Low-noise
  • Shielded power supply compartment for reduced interference with delicate electronics

• PHYSICAL:

  • FINISH:

    • Black anodised aluminium
    • Raw anodised aluminium

    DIMENSIONS

    • 350mm (W), 350mm (D), 60.5mm (H), 6kg
