Lehmann Linear Headphone Amplifier
Taxes & Shipping Included
Already since 2004 the Linear has made all common headphones to shine at their very best. Extremely demanding users rely on our top model, from the West German Broadcasting Corporation to the audiophile TACET label to Sennheiser’s and AKG’s headphone experts. It’s not without reason that the Linear belongs to the reference class in its genre. When you put on your headphones and load your favourite CD, the Linear will give rise to wonderful worlds before your mind’s eye. Physical, punchy lows and a delicate resolution reveal your favourite tracks in all their glory over the entire frequency bandwidth. Carefully selected components and an extremely sophisticated circuit design establish the foundation of our number on.
With three gain settings it gives you an impressive listening pleasure, keeping an eye on your needs anytime – and this using a vast array of headphones on the most diverse sound sources. In this context we have, of course, taken into account the varying performance requirements and sensitivity levels of the headphone types currently available on the market.
If you would like to share your joy at this quality of music reproduction with family and friends, our multiple test winner will be happy to feed two headphones at the same time. Of course, the listening enjoyment will remain equally fabulous then. The two parallel outputs of the discrete class A solid-state output stage provide the basis of this double musical enjoyment.
A propos: if you wish so, the Linear will also stimulate your active speakers to a stunning vitality. In every situation a magnificent sound, always striving for perfection – such is our Linear.
Features
- Reference class headphone amplifier for all dynamic headphones ≠ maximum gain adjustable up to 20 dB
- Discrete zero global feedback Class A output stage for open and natural sound
- Oversized internal power supply
- Two headphone connections with goldplated Neutrik headphone sockets
- Low-loss MKP capacitors for the audio path
- Drives long cable runs when used as single source preamplifier
- Aluminium face plate available in silver, black or chrome
- Made in Germany
Specifications
| Input impedance | 47 kohms |
| Maximum gain | 0 dB, 10 dB, 18 dB, 20 dB selectable via DIP switches |
| Frequency response | 10 Hz (-0.3 dB) to 35 kHz (-1 dB) |
| Signal to noise ratio | > 95 dB at gain 0 dB |
| THD | < 0.001 % at 6 mW/300 ohms |
| Channel separation | > 70 dB at 10 kHz |
| Output power | 400 mW/60 ohms 200 mW/300 ohms |
| Output impedance | pre-out 50 ohms phones out 5 ohms |
| Connectors audio | Neutrik headphone jacks with gold plated contacts 1 x pre-out 2 x phones out gold plated RCA sockets with teflon insulation |
| Power consumption | 10 W |
| Outer dimensions W x D x H | 110 mm x 280 mm x 50 mm |
| Weight | 1.5 kg netto |
Support
Awards & Reviews
About
Lehmannaudio Vertriebs GmbH was originally founded in 1988 by Norbert Lehmann, a young audio engineering student, in Cologne, Germany. Through those early days, Norbert developed a deep understanding of how the quality of certain electrical devices affected the end sound-performance of an amplifier. The cumulative result of this formative period was manifest in 1995, when Lehmannaudio released the Black Cube phono stage.
The Black Cube is now a cult object in the audiophile market. Still available today in almost the same form as the original model, the Black Cube took components more commonly found in studio mixing desks and brought them to a hi-fi product. The result was an affordable phono stage that sounded truly sublime. In 2004, the next icon was born; the Linear Headphone Amplifier (originally called Black Cube Linear) again took studio principles and brought them to the hi-fi sector, allowing hi-fi fans to experience the true engineering ability of Norbert Lehmann.
Since 2004 the phono stage and headphone amplifier sectors have been happy homes for Lehmannaudio products, and now the company can boast a range of products in each sector that are suitable for all budgets and technical requirements.
