Features
- 3-Way Bookshelf Design revives the spirit of the original 1969 Concerto speaker
- Incorporates META Metamaterial Absorption Technology
- 12th Generation Uni-Q driver
- Refined Crossovers
- Aural match with other Q Series speakers for a full HT setup
- Matching SQ1 Floor Stands (Optional)
- Magnetic Grilles
Specifications
- Design Three-way bass reflex
- Drive units Uni-Q Driver Array: HF: 19 mm (0.75 in.) vented aluminium dome with MAT, MF: 100 mm (4 in.) aluminium cone, Bass Unit: LF: 165 mm (6.5 in.) hybrid aluminium cone
- Frequency range (-6dB) 40 Hz - 20 kHz
- Typical in-room bass response (-6dB) 36 Hz
- Frequency response (±3dB) 48 Hz - 20 kHz
- Crossover frequency 430 Hz, 2.9 kHz
- Amplifier requirements 15 - 180 W
- Sensitivity (2.83V/1m) 85 dB
- Harmonic distortion (90dB, 1m) <2% 37 Hz and above, <1% 91 Hz - 20 kHz
- Maximum output 108 dB
- Impedance 4 Ω (min. 3.2 Ω)
- Weight 9.5 kg (20.9 lbs.)
- Dimension (H x W x D) with terminal 415 x 210 x 315 mm (16.3 x 8.3 x 12.4 in.)
- Finishes Satin Black / Satin White / Walnut
