JL Audio Fathom f212v2 - Dual 12inch Powered Subwoofer
The challenges associated with designing high-output compact subwoofer systems can be quite daunting. In most cases, designers sacrifice low-frequency extension or output capability in order to keep the design small.
The Fathom® v2 subwoofers sacrifice nothing, thanks to the dynamic advantages of their proprietary JL Audio woofers. These exceptional drivers allow for a true subwoofer passband and very high output, while keeping distortion well below audible thresholds. To extract full benefit from the excursion envelope of its woofer, each Fathom® v2 employs an exceptionally powerful switching amplifier with a large toroidal transformer and a patented circuit designed to enhance control and fidelity.
The compact design and conventional form factor of the Fathoms apply beautifully to most home theater applications, including built-in designs. Front-mounted controls make them a dream to set up and adjust, while JL Audio’s exclusive Digital Automatic Room Optimization circuit makes sure that response is smooth, even in challenging rooms.
Simply put, Fathom® v2 is the compact subwoofer system for those who enjoy demanding program material and won’t settle for compromises.
The f212v2 is the ultimate expression of the Fathom formula. It is ideal for larger spaces thanks to its higher efficiency and higher power output. The combination of dual ultra-long throw W7 12-inch drivers and a very powerful switching amplifier give it jaw-dropping performance capabilities at any listening level.
Because it is built with the same driver and amplifier technology as our flagship Gotham®, the f212v2 delivers a tremendous level of sound quality. Low distortion, excellent dynamic capabilities and shockingly deep bass extension will allow you to experience all the excitement of the most demanding cinematic material, while also being able to reproduce all the nuance and texture of your most delicate musical material.
A complete set of signal processing features is easily accessible on the front surface of every Fathom. These include a highly flexible low-pass filter, variable phase, switchable polarity, e.l.f. trim and our powerful Digital Automatic Room Optimization (D.A.R.O.) system. A calibrated microphone is included for the D.A.R.O. system. Input connections are made via unbalanced RCA connections or balanced Neutrik® combo XLR/TRS jacks. Also included is an XLR output to connect a second Fathom® as a slave unit.
|Enclosure Finish||Black Gloss|
|Frequency Response (Anechoic)||20 - 97 Hz (±1.5dB) -3 dB at 19 Hz / 110 Hz -10 dB at 15 Hz / 157 Hz|
|Effective Piston Area (Sd)||168 sq in / 0.1084 sq m|
|Effective Displacement||574 cu in / 9.4 L|
|Amplifier Power||3.6 kW RMS short-term|
|Power Mode(s)||Off, On or Automatic (Signal-Sensing)|
|Light Modes||Off, On or Dim|
