Jay's Audio CDT2-MK3 CD Transport
Taxes & Shipping Included
In an era dominated by convenience-driven streaming, the Jay’s Audio CDT2-MK3 stands as a defiant, beautifully engineered monument to the enduring supremacy of physical media. Far from a nostalgic relic, this pure Redbook CD transport treats the humble compact disc not as yesterday’s format, but as a high-fidelity treasure trove waiting to be unlocked. By stripping away internal digital-to-analog converters and focusing solely on flawless digital extraction, Jay's Audio has crafted a purist components machine that challenges five-figure digital front-ends. It is a tactile, top-loading statement piece for the discerning audiophile who understands that the journey to sonic perfection begins at the absolute source.
Features
- Philips CDM4/19 Mechanism: Features a selected and tested premium top-loading laser mechanism known for its longevity and excellent tracking.
- OCXO Clocking: Equipped with an Oven Controlled Crystal Oscillator (OCXO) coupled with a precise PLL circuit to minimize digital jitter.
- Configurable Sampling: Allows native 44.1kHz playback or upsampling to 176.4kHz via the machined aluminum remote control.
- Robust Power Supply: Built with UK Noratel encapsulated transformers, multi-stage super regulators, and Gold Tune capacitors.
- Customizable I²S Pinout: Features adjustable dip-switches on the back to match the HDMI I²S configuration of various DAC brands.
Specifications
- Philips CDM4 Mechanism
- Schurter IEC Inlet
- Improved AC Noise Filter
- UK Noratel Encapsulated Transformers
- Multistage Super Regulator with Gold Tune Caps
- Neutrik XLR
- Oven Controlled Crystal Oscillator OCXO
- i2s LVDS Output
- Digital Output Isolation Transformer
- Native/Upsampling 44.1kHz / 176.4kHz Configurable via Remote Control
- Supported Formats: Redbook CD, CDR, CDR/W only [Redbook CD transport only. Doesn't support HDCD/SACD/DSD]
- Digital Output:
- COAX (RCA/BNC) 2v @ 75ohm
- XLR 5V @110ohm
- HDMI i2s LVDS
- Sampling Rate: 44.1kHz, 176.4kHz
- AC Power: 230V
- Dimension: 430mm x 380mm x 120mm
- Weight: 15KG
Support
Awards & Reviews
About
Jay's Audio is a premier boutique manufacturer globally renowned for its singular, uncompromising dedication to the art of reference-class Redbook CD playback. Founded with a mission to preserve and maximize the potential of the physical compact disc format, the brand has earned legendary status among audiophiles for its meticulous craftsmanship, massive over-engineered chassis, and reliance on iconic, vintage optical mechanisms like the Philips CDM4 swing-arm and CD-Pro2 linear-tracking lasers. By rejecting the modern trend of multi-format compromises, Jay's Audio focuses exclusively on mastering digital-to-digital transcription through ultra-premium linear power supplies, oven-controlled crystal oscillators (OCXO), and extensive physical isolation. The result is a highly acclaimed lineup of digital transports that bridge the gap between digital accuracy and analog fluidity, standing as a definitive benchmark for high-end optical disc systems worldwide.
