Eversolo DAC-Z8 DAC & Preamplifier
Taxes & Shipping Included
The Eversolo DAC-Z8 combines professional-grade audio processing with elegant simplicity. Built around the ESS ES9038 Pro DAC chip and third-generation XMOS 316 processor, it decodes high-resolution formats including DSD512 and PCM 768kHz with precision. Its integrated preamplifier and headphone amplifier deliver refined sound across multiple input options, while the intuitive multi-function control knob and compact footprint make it an understated addition to any serious listening setup. Whether paired with reference headphones or audiophile speakers, the DAC-Z8 offers transparent, detailed reproduction for discerning listeners.
Fully-Balanced Analog Audio Circuit
The analog audio circuitry takes maximum advantage of a fully balanced design. The XLR, RCA, and headphone output are all processed by a balanced differential amplifier circuit. The noise has been eliminated by resolving the crosstalk of the shared loop and improving channel separation. The high-fidelity preamp circuit supports refined volume adjustment, negating the need for connection to an external preamp.
In order to reduce any possible signal interference of the Z8's RCA and XLR output, the RCA and XLR signals are output separately for best audio performance. However, if you prefer, the RCA and XLR signals can be output simultaneously by setting them up in this fashion manually.
Benefiting from the EverSolo development engineers' rich experience in analog circuit design, the DAC-Z8 has professional calibration and circuit design. The total harmonic distortion ratio (THD) is an impressive -124dB (0.000062%), while signal-to-noise ratio and dynamic range are 133dB. These industry-leading indicators are solid foundation for good sound quality.
Industry-Leading Digital Circuitry
The DAC-Z8 goes first class with its DAC. The flagship ESS ES9038Pro DAC is known as the industry benchmark, boasting low total harmonic distortion, plus extremely low noise and distortion.
The third generation XMOS 316 has fast processing speed and better USB bandwidth, which ensures lossless transmission for high-definition audio data. The USB output supports DSD512 Native, PCM768@32bit and MQA full decoding. The optical and coaxial output support DSD 64 (DoP) and PCM192@24Bit.
Tailor the sound the way you like! A selection of different digital filter modes in DAC settings give you a host of options. Choose from seven PCM filters and four DSD filters to suit the demands of a range of source material.
High-Performance Headphone Amplifier
Enjoy headphone listening to the max. The professional headphone circuit has excellent audio and strong driving force, which means DAC-Z8 can be used as a high-performance headphone amplifier and drive 16-300ohm headphones. With its choice of high and low gain output options.
A Generous Selection of Inputs
The DAC-Z8 gives you a number of digital audio inputs, including coaxial, optical, and asynchronous USB DAC (type-C for computers and mobile devices). The APT HD Bluetooth audio input can be used to connect with computers, streamers, CD players, phones, tablets, and more.
The built-in Bluetooth audio receiver is based on the Qualcomm QCC5125 module. It is Bluetooth 5.0 and supports SBC, AAC, aptX, apt LL, and aptX HD/LDAC Bluetooth audio protocol.
MQA Playback
The DAC-Z8 includes MQA (Master Quality Authenticated) technology, which enables you to play back MQA audio files and streams, delivering the sound of the original master recording.
Dual Low Jitter Clock Oscillators
Two low jitter clock oscillators (45.1584MHz and 49.152MHz) are integrated in DAC-Z8, which correspond to 44.1 KHz and 48KHz multiplied sampling management. As a result, audio decoding is more accurate.
OPA1612 I/V Circuitry
The DAC-Z8's I/V circuit is made up of eight OPA1612 chips. The multichannel signal shunt compensation technology has been adopted, with eight OPA1612s corresponding to eight-channel output for I/V signal conversion, then output to two channels in parallel.
The I/V stage converts signal currents into voltage signal and is located in between the DAC current output and the first amplification stage. Here it improves channel separation, dynamic range and the sound integrity.
Low-Ripple Power Module
A low-noise, highly regulated power supply module and dedicated an ultra low-noise audio filter capacitor are tailored for DAC-Z8. It powers the audio circuit and ensures clearer sound, with low ripple and very low interference.
Control App and Front-Panel Control
THE DAC-Z8 can be easily controlled by mobile phone and other devices with the EVERSOLO Controller app. Almost all settings can be done in the APP via Bluetooth technology.
As a convenient alternative, the knob on the front panel is multifunctional. It can be used for volume adjustment, menu selection, input source switching, output selection, filter modes, UV meters, system language setup, firmware updates, and much more.
The three-inch LCD display on the front panel shows the colorful user interface of menu setting, audio source selection, VU meter, and audio info.
Attractive Aluminum Chassis
The aluminum chassis is made of aviation aluminum, attractively combining an exquisite, timeless appearance with modern design elements.
Features
- ESS Sabre flagship ES9038Pro 32 bits D\A converter chip.
- The 3rd generation USB XU316 with higher performance and faster speed.
- High precision, low jitter dual clock oscillators synchronous processing.
- OPA1612*8 I/V operational amplifier circuit, 8-channel shunt compensation technology.
- Up to DSD512 Native, PCM768KHz@32Bit decoding.
- Optical, Coaxial and USB support MQA full decoding and rendering.
- Qualcomm QCC5125 Bluetooth 5.0 module.
- High-performance headphone amp output, 16-300 ohm headphone driver
- Fully balanced audio architecture, differential amplifier circuit and professional calibration.
- High-performance headphone amp output, 16-300 ohm headphone driver.
- 3-inch LCD screen, with diverse VU meter modes.
- Low ripple power supply to ensure a purer power source.
- Exclusive mobile phone controller APP for global control.
Specifications
- Model EverSolo DAC-Z8
- Display Screen 3-inch LCD Screen
- Chassis Aviation aluminum alloy
- DAC ES 9038Pro
- Audio Processor USB XU316
- OPA Chip OPA1612*10
- Power Supply Low noise switching power supply
- Bluetooth Audio Input Qualcomm QCC5125 Bluetooth module, BT5.0 Support SBC/AAC Bluetooth protocol
- USB-B DAC Input. Compatible with Windows (7, 10), Mac, Android and IOS Up to stereo DSD512, PCM 768KHz 32Bit and MQA
- USB-C DAC Input Compatible with Windows (7, 10), Mac, Android and IOS. Up to stereo DSD512, PCM 768KHz 32Bit, MQA
- Optical Audio Input. Up to stereo PCM 192KHz 24Bit, DSD64 Dop and MQA
- Coaxial Audio Input. Up to stereo PCM 192KHz 24Bit, DSD64 Dop and MQA
- Analog Audio Output
- Preamp output: XLR (balanced), RCA;
- Headphone amp output: 6.35mm single-ended
- USB Port USB2.0*1（only for firmware upgrade）
- Control Methods Remote control, mobile APP control and knob control
- Headphone Impedance 16-300Ω （low gain mode:16-32Ω/high gain mode: 32-300Ω）
- XLR Audio Characteristics
-
Output level(Vrms): 4.1Vrms@0dBFS
- THD+N@A-wt: 0.000062%@1kHz（-124dB@1kHz）
- THD+N@No-wt：0.000069%@1kHz（-123dB@1kHz）
- Noise@No-wt: <1.2uVrms
- SNR @No-wt: 133dB@1kHz
- Frequency response: 20Hz-20kHz(±0.1dB)
- Crosstalk: -130dB@1kHz
- DNR @No-wt: 133dB@1kHz
-
RCA Audio Characteristics
- Output level (Vrms): 2.3Vrms@0dBFS
- THD+N@A-wt: 0.000086%@1kHz(-121dB@1kHz)
- THD+)@No-wt: 0.000097%@1kHz(-120dB@1kHz)
- Noise @No-wt: <1.5uVrms
- SNR @No-wt: 126dB@1kHz
- Frequency response: 20Hz-20kHz(±0.1dB)
- Crosstalk: -123dB@1kHz
- DNR@No-wt: 126dB@1kHz
-
Headphone (low gain mode)
- Output level(Vrms): 1.2Vrms@0dBFS
- Maximum undistorted power: 45 mW@32Ω
- THD+N@A-wt: 0.00015%@1kHz(-116dB@1kHz)
- THD+N@No-wt: 0.00018%@1kHz(-115dB@1kHz)
- Noise @No-wt: <2uVrms
- SNR@No-wt: 124dB@1kHz
- Frequency response: 20Hz-20kHz(±0.1dB)
- DNR @No-wt: 119dB@1kHz
-
Headphone (high gain mode)
- Output level(Vrms): 2.8Vrms@0dBFS
- Maximum undistorted power: 26 mW@300Ω
- THD+N@A-wt: 0.00016%@1kHz(-116dB@1kHz)
- THD+N@No-wt: 0.00016%@1kHz(-116dB@1kHz)
- Noise@No-wt: <2uVrms
- SNR@No-wt: 124dB@1kHz
- Frequency response): 20Hz-20kHz(±0.1dB)
- DNR @No-wt: 124dB@1kHz
- Power Input AC 110~240V 50/60Hz Max 0.35A
- Rated Power 9W
- Dimensions 270mm(W) * 187mm(D)* 50mm(H)
- Packing List Remote control*1, power cable*1, USB cable*1, product manual*1
