EAM Lab CLASSIC 302i Integrated Amplifier
Taxes & Shipping Included
Our integrated amplifier CLASSIC 302I has been designed, engineered, and developed to elevate the audio experience. Based on our previous ELEMENT series models, it incorporates the latest innovations in
connectivity and digital streaming, delivering an even clearer, more detailed, and immersive sound. We are proud to declare that this new generation of low-noise, high-harmonic contrast circuits marks the start of a true sonic revolution. Thanks to cutting-edge circuit design, a modern volume control system, next-generation components, and advanced features, CLASSIC 302I ensures precise, distortion-free, and dynamic sound. One of its main features is the ability to amplify the audio signal without alterations, maintaining a high dynamic range and reproducing music with absolute fidelity. Its powerful power supply eliminates background noise and distortion, delivering pure and engaging listening. The CLASSIC 302I is extremely versatile: it offers numerous audio inputs and outputs, including an excellent MM phono input, two balanced inputs, and three line inputs, making it compatible with a wide range of sources, from CD players to turntables. Moreover, the integrated Hyperstream DAC, based on SABRE ESS 9038 q2m technology, further expands the digital connection possibilities, offering unparalleled playback quality. Designed for ease of use and setup, its intuitive interface allows you to configure it in minutes, so you can immediately immerse yourself in an extraordinary sound world.
Balanced Circuitry and Dual Mono
In the new 302I, we have significantly increased the power supply stage and developed the entire project with a dual mono architecture. Each channel has separate, optimally filtered, and stabilized power supplies, as well as independent ground planes. This configuration ensures extremely effective channel separation, translating into a very natural sound with incredible and realistic focus and soundstage reconstruction. The wiring has been minimized; the conversion of line inputs to balanced and the ability to integrate the system with audio/video setups ensures absolute and long-lasting performance. The design is completed by a highperformance PHONO RIAA section, ideal for vinyl enthusiasts, and the option to use PRE-OUT / AMP-IN outputs, conveniently selectable via remote control, for unprecedented versatility.
Balanced Circuitry Philosophy
We understand there are many differing opinions about this configuration. Some say it is unnecessary in home settings, others that it might degrade or dirty the sound, and still others that see it only as a way to increase the cost of devices for commercial reasons. However, these claims might only be true if this part of the project is neglected or designed superficially. Recent field tests have shown that if the overall design is carried out with care and attention, the final result can be truly exceptional in terms of musicality, transparency, and dynamics. In the CLASSIC 302I, nothing was left to chance: from the dual mono power supply and circuitry to the very heart, where each amplification section is doubled. Even the volume control is innovative, using two separate stages per channel, digitally controlled via a mosfet array. Additionally, thanks to its native balanced nature, even single-ended line inputs are fully converted to balanced, including the PHONO RIAA stage. Simply put, you won’t hear a more dynamic and transparent preamplifier than this.
Volume control section
This is the most delicate and fundamental stage, to be handled with extreme care, because it ultimately determines the overall playback performance. Unlike many manufacturers who use classic motorized potentiometers, we have developed a completely different stage that guarantees a set of very important performance advantages. We have implemented gain control via a shielded mosfet array within a dedicated IC, digitally controlled. As a first benefit, we have permanently eliminated the wear of the carbon layer typical of traditional potentiometers, permanently erasing the onset of annoying hum & noise and pop & click inevitable over time. Another often-overlooked advantage is the response linearity that changes with volume increase or decrease when using carbon layer potentiometers or even the more sophisticated resistor array potentiometers. This happens when the signal passing through the potentiometer encounters a resistance that alters the impedance factor, causing this artifact. Thanks to our technology, this problem has been definitively eliminated because the signal does not see a resistance that varies with the knob but a network of mosfet devices acting directly on the feedback of a high-impedance, high-bandwidth operational amplifier.
DAC section
The 302I is equipped with a state-of-the-art DAC stage that further expands the inputs for new digital technologies. Three additional inputs—USB, COAX, and OPTICAL—make the amplifier extremely versatile with a wide range of connection options to best enjoy music from your preferred source, whether streaming, a CD player, or a television. The DAC reads files with conversion up to 768 kHz in PCM and DSD 512 in Dop or DSD 1024natively. The DAC board is also replaceable and upgradable at any time to always have the latest digital audio innovations at your fingertips. Practical and Functional Connections
Practical and Functional Connections
The multiple connections make it versatile in any system, as a pure integrated amplifier or also as a preamplifier/power amplifier, integrating into already existing complex systems. To leave nothing to chance, the dedicated PRE-OUT and AMP-IN outputs can also be managed in balanced connection and are enabled from the practical touchscreen display or remote control. All functions are visible on the main screen—simple, intuitive, practical! From the SETTINGS menu, you access the second page where you can set all secondary functions, such as: DAC settings, input gain, fixed volume inputs for audio/video system integration, EXTERNAL use as pure final
Features
- Dual mono architecture
- High flux density transformers
- Stable at 2 ohms
- Latest generation bipolar transistors
- Volume control in the mosfet array digital domain
- Integration into audio video systems
- Wide connection possibilities
- Native balanced input-to-output structure
- Conversion of line data flow via RCA into balanced signal
- Extreme power, 2 x 1000 Wrms @ 2ohm
- Dynamic Crest factor >20db
- Made in Italy
Specifications
- RMS power for channel , both chanel driven @1Khz
- 300 W @ 8 ohm
- 600 W @ 4 ohm
- 1000 W @ 2 ohm
- EIA power for channel , both chanel driven / 20hz- 20Khz.
- 450 W @ 8 ohm
- 720W @ 4 ohm
- THD + N – weight A - 0.003% @ nominal power 8 ohm
- Input
- 2 balanced input via XLR
- 3 line input
- 1 phono input RIAA MM
- 1 ingresso AMP-IN selezionabile
- Output
- 1 pair of XLR PRE-OUT
- 1 pair of Binding post 6mm
- Input impedance
- 47 Kohm via XLR
- 22 Kohm via RCA
- Slew/rate 35 V/uS
- Frequency response 20 hz ~ 90 Khz +/- 0.2 db
- Phono input MM – 47Khom – 41 db gain
- DAC section USB – 784 Khz pcm – DSD256 in Dop mode / DSD 512 nativo COAX / Optical
- Chanel separation > 83 db
- SNR weight A >108 db
- Dimension 46 ––x 42 x 21 cm. ( P x L x H )
- weight 42 kg
- remote control included
