Atoll AM200 Evolution Stereo Power Amplifier

Atoll AM200 Evolution Stereo Power Amplifier

by Atoll
₹ 195,200 - ₹ 195,200
₹ 195,200
₹ 195,200
₹ 195,200 - ₹ 195,200
₹ 195,200

Taxes & Shipping Included

Color: Black

The Atoll AM200 Evolution Power Amplifier is suitable for most HIFI or audio-video applications. Very scalable, it can be used alone or in bi-amplification. It can be associated with an integrated amplifier or an ATOLL preamplifier. It is bridgeable in a monoblock via an internal switch. It is equipped as standard with a 12V Trigger input (direct ignition in conjunction with a preamp).

Our balanced MOS-FET amplifier circuits offer excellent harmonic gradients and have no memory effect, every moment, the current is immediately delivered to your speakers. This is one of the secrets of the musicality that ATOLL amplifiers enjoy.

Features
  • 8 mm brushed aluminium front panel
  • 2 × 120 W @ 8Ω / 2 × 200 W @ 4Ω
  • 1.5 mm steel chassis
  • Two 340 VA toroidal transformers each
  • High-quality and shielded MKP link capacitors
  • Bipolar transistor and LED current sources to ensure perfect voltage stability
  • Discrete balanced audio stages
  • MOS-FET power transistor
  • Class A/B output stage biasing
  • Custom PCB with nickel/gold finish
  • Mono block bridgeable
  • New tellurium copper speaker outputs
  • 12V Trigger input
  • Made in France
Specifications
  • Output power Wrms/8Ω: 2×120 W
  • Output power Wrms/4Ω: 2×200 W
  • Pulse power/channel: 300 W
  • Power supply: 2 x 340 VA
  • Total of capacitors: 59,420 µF
  • Number of inputs: 1 x RCA
  • Consumption with switch off: 0 W
  • Consumption in operation: 20 W – 600 W
  • Input impedance: 220 kΩ
  • Sensitivity: 1.77 V
  • Signal/noise ratio: 100 dB
  • Distortion at 1 kHz: 0.05%
  • Bandwidth: 5 Hz – 200 kHz
  • Rise time: 1.5 µs
  • Dimensions: 440×295×95 mm
  • Weight: 12 kg
