ASR Mini Basis Phono Preamplifier

by ASR
₹ 265,000 - ₹ 375,000
₹ 265,000
₹ 265,000
₹ 265,000 - ₹ 375,000
₹ 265,000

Taxes & Shipping Included

Vaiant: Mini Basis

The ASR Mini Basis is a phono preamplifier for Moving Magnet (MM) and Moving Coil (MC) pickup systems. Like all ASR amplifiers, the technology of the “small” ASR phono preamplifier Mini Basis is built into a housing made of high-quality, slightly transparent acrylic glass.

A variety of adjustment options through input resistance and amplification allow each pickup to fully exploit its inherent sound qualities.

Not least thanks to the sophisticated power supply, the ASR Mini Basis sounds very dynamic, with a very powerful and controlled bass. The sound has a precise spatiality and is combined with a very good resolution of details.
The sound is typical of ASR products, very relaxed and unobtrusive.

As with the emitter, many additional customer requests in the area of ​​equipment can be realised.



Features

  • Housing made of low-resonance, slightly transparent acrylic glass
  • Highly efficient, shielded 72 VA PM (Philbert jacket cut) transformer
  • Particularly high-quality core sheet with low stray field for high dynamics
  • Ultra-fast and low-loss Schottky diodes, 200,000 uF screening
  • Extremely fast and low-noise measuring amplifier ICs
  • Adaptable to MM and MC pickups using two DIP switches
  • Input resistance can be switched with a 10-fold DIP switch between 12 and 47,000 ohms (47KOhm)
  • Gain adjustable with 6-way DIP switch from +30 dB to +70 dB

        Specifications

        Mini Basis

        • Signal-to-noise ratio > 60dB (depending on the settings)
        • RIAA equalization < 1dB deviation from 20Hz to 20kHz
        • Distortion < 0.01% THD
        • Transformer 72 VA
        • Total sieve capacity 200,000uF
        • Fuse 500 mA slow
        • Dimensions and weight W x D x H 268 mm x 350 mm x 110 (HV130) mm - approx. 5 kg

        Mini Basis Exclusive

        • Even better high-end ICs
        • Power cable ASR Magic Cord 150 cm, other lengths upon customer request
        • IC heatsink made of solid brass for low resonances
        • Special diodes with even faster operation
        • Optionally with balanced output (XLR)
        • Font available in chrome or gold
        • Optional RCA sockets from WBT nextgen copper or silver

          Mini Basis Exclusive HV

          • 40 volt ASR capacitors with 200,000 uF
          • 2 cm higher housing
